Description of  LC1G150KUEN

 TeSys Giga high power contactor, 3 poles (3 NO) for category AC-3 applications up to 150A 90kW@440V. It provides a 100-250V AC/DC wide band low consumption electronic coil and embedded highly reliability 1NO+1NC auxiliary contact block (17V 1mA). Designed for demanding applications with maximum operating rates up to 600 cycles per hour and environments until 60°C. It procures high reliability and durability with 5 Mcycles mechanical durability. Local Contact Wear Diagnosis (CWD) as standard function, continuous monitoring with healthy and alarm indicators. It is possibility to replace switching module (main contacts), enhancement contactor life. Contactor can be fixed in all quadrants, maintenance without removing cables/busbars, and OLR could be directly mounted below contactor. To be used with power connection by bolted connection and control connections by spring terminals, accessible from front for easy and quick replacement. It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106. It can cover -25°C to 60°C operation ambient air temperature and directly mounted on plate, No derating up to 3000m altitude. The dimension is 255mm x 108mm x 175mm (H x W x D), compact size enables panel space savings. Multi standards certified(CE,CB,CCC,cULus,EAC,KC,RCM,Marine) and Green Premium compliant (RoHs/Reach). Unique QR code provides quick access to complete product data.

1. Voltage Rating: Suitable for AC applications, with a voltage rating of up to 690V.

2. Current Rating: The contactor is rated for up to 150 A, making it ideal for high-load applications.

3. Application: Primarily used for switching electrical circuits and controlling motors, heating equipment, and other heavy-duty electrical loads.

4. Technology: It utilizes electromagnetic technology for reliable switching, with a compact and durable design for long-lasting performance.

5. Compatibility: Often used in conjunction with other Schneider Electric components for complete motor control or automation systems.

6. Auxiliary Contacts: Includes auxiliary contacts for signal feedback or control purposes.

7. Mounting: Designed for DIN rail mounting, making it easy to install and replace.

8. Safety Standards: Complies with international standards for safety, reliability, and performance.

Advantages:

• High Reliability: Ensures long-term reliability in industrial environments.

• Energy Efficiency: Offers energy-efficient performance when integrated into automation systems.

• Easy Integration: The design allows for seamless integration with other Schneider Electric products, optimizing operational efficiency.
