FR-E540-3.7K - Frequency inverter - MITSUBISHI Inverter, AC Drive
Description
- Up to 10 hp at 240 VAC and 480 VAC.
- Advanced Magnetic Flux Vector Control.
- Auto-tuning.
- 50°C maximum ambient temperature.
- RS-485 serial communication (standard).
- Selectable cooling fan operation mode.
- Built-in PID control.
- Adjustable carrier frequency (0.7kHz to 14.5kHz).
- Optional keypad interface (FR-PA02-02).
- Compatible with FR-PU04 user interface.
- UL & cUL listed / CE marked.
- Available configuration software for Windows® 95 / 98.
- Open-network communication options
TECHNICAL SPECIFICATIONS
Model:FR-E540-3.7K-NA
Brand:MITSUBISHI
Product Condition:New with Defects or Obsolete
Horsepower Rating:5 HP
HP Rating @ 150% OL:5 HP
Rated Amps:9.5 A
Amp Rating @ 150% OL:9.5 A
Rated Voltage:460 V
Output Voltage:460 V
Output Amperage Rating:9.5 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Enclosure Rating:IP 20
Series:E500
Height:5.90 in
Width:5.50 in
Depth:5.40 in
