R88D-GT04H-Z OMRON Industrial Servo Drives 200-230 V -≤2200ml/Min 1200W
R88D-GT04H-Z Description
The R88D-GT04H-Z is a high-performance, compact single-phase AC servo drive from Omron’s G-Series (Accurax G5 platform), engineered for precise motion control of 400W-class servo motors. Operating on 200–240VAC single-phase input, it supports position, speed, and torque control modes via pulse train or analog command inputs, delivering high dynamic response and sub-micron positioning accuracy. This drive integrates advanced auto-tuning, vibration suppression, and built-in safety functions (STO), with a slim panel-mount design (IP10) optimized for space-constrained industrial machinery. It is fully compatible with Omron R88M-G series 400W servo motors (e.g., R88M-G40030H-S2) and supports 20-bit high-resolution encoder feedback for ultra-precise motion control.
R88D-GT04H-Z Key Features
- Triple Control Modes: Full support for position control (pulse input), speed control (analog/pulse), and torque control (analog) for versatile motion applications.
- High Dynamic Performance: 2kHz speed loop frequency response, fast acceleration/deceleration, and stable low-speed operation down to 0 rpm.
- Advanced Tuning & Stability: Real-time auto-tuning, anti-vibration control, torque feedforward, and disturbance observer to eliminate machine resonance and improve positioning accuracy.
- High-Resolution Feedback: Compatible with 20-bit incremental encoders (1,048,576 pulses/rev) for ultra-precise position and speed feedback.
- Built-In Safety Function: STO (Safe Torque Off) compliant with ISO 13849-1 Cat.3 PLd, enabling safe stop without disconnecting main power.
- Compact & Space-Saving: Slim form factor (65×150×132 mm) for panel mounting in tight control cabinets, IP10 protection rating.
- Rich I/O & Connectivity: 10 digital inputs, 4 digital outputs, 2 analog inputs; supports pulse/direction, CW/CCW, and analog command interfaces.
- Comprehensive Protection: Overcurrent, overvoltage, undervoltage, overheat, motor overload, encoder error, and short-circuit protection for reliable operation.
- Easy Setup & Monitoring: LED status indicators, parameter setup via keypad/software, and real-time monitoring of torque, speed, and position.
- Global Compliance: CE, UL, RoHS certified for worldwide industrial deployment.
R88D-GT04H-Z Materials & Applications
Materials
- Housing & Frame: High-strength flame-retardant reinforced engineering plastic (UL94 V-0) with aluminum alloy heat sink for efficient thermal dissipation.
- Power Stage: High-performance IGBT modules with low switching loss, high thermal stability, and long service life.
- Control Circuit: Multi-layer FR-4 PCB with surface-mount components, conformal coating for dust and moisture resistance in industrial environments.
- Cooling System: Forced-air cooling with a long-life, low-noise fan; aluminum heat sink for optimal heat dissipation.
- Terminals: Nickel-plated copper terminals for secure, corrosion-resistant electrical connections.
- Internal Components: High-temperature electrolytic capacitors, precision current/voltage sensors, industrial-grade microcontroller, and isolated encoder interface for stable performance.
Typical Applications
- Packaging Machinery: Labelers, cartoners, sealers, filling machines, and high-speed packaging lines requiring precise positioning.
- Machine Tools: Small CNC machines, engravers, grinders, lathes, and linear positioning tables.
- Semiconductor & SMT Equipment: Pick-and-place machines, PCB assembly, chip handlers, and precision testing equipment.
- Robotics & Automation: Small robotic arms, SCARA robots, end-effectors, and assembly line actuators.
- Printing & Textile: Winding machines, slitters, printers, and embroidery equipment with high-speed, stable motion.
- Material Handling: Conveyors, feeders, palletizers, and sorting systems with variable speed and positioning control.
- General Industrial Automation: Rotary tables, indexing machines, and automated assembly stations.
R88D-GT04H-Z Important Parameters
| Parameter |
Specification |
| Part Number |
R88D-GT04H-Z |
| Brand |
Omron (G-Series / Accurax G5 Servo Drive) |
| Drive Type |
Single-Phase AC Servo Drive (Pulse/Analog Input) |
| Rated Output Power |
0.4 kW (400 W) |
| Input Power |
Single-phase AC 200–240 V, 50/60 Hz |
| Rated Input Current |
3.7 A |
| Rated Output Current |
2.7 A |
| Peak Output Current |
7.1 A (300% of rated) |
| Control Modes |
Position Control (Pulse), Speed Control (Analog/Pulse), Torque Control (Analog) |
| Encoder Compatibility |
20-bit Incremental Encoder (1,048,576 ppr) |
| Speed Loop Response |
2 kHz |
| Maximum Output Frequency |
300 Hz |
| Protection Rating |
IP10 (Panel Mount) |
| Safety Function |
STO (Safe Torque Off), ISO 13849-1 Cat.3 PLd |
| Cooling Method |
Forced Air Cooling |
| Ambient Operating Temperature |
0°C to +55°C |
| Storage Temperature |
-20°C to +65°C |
| Humidity |
5–90% RH (Non-Condensing) |
| Vibration Resistance |
5.88 m/s² (0.6 G) |
| Shock Resistance |
19.6 m/s² (2 G) |
| Dimensions (W×H×D) |
65 × 150 × 132 mm |
| Weight |
Approx. 1.1 kg |
| Certifications |
CE, UL, RoHS, EN 61800-3 (EMC) |
| Compatible Motors |
Omron R88M-G Series 400W Servo Motors (e.g., R88M-G40030H-S2) |
