Product Details:
Payment & Shipping Terms:
|
| PN: | 12P2093Xxxx | LocalBus Power Rating: | 5VDC 1.4A Max. |
|---|---|---|---|
| Ambient Temperature: | 0℃-60℃ | Warranty: | One Year |
| Another Model: | VE3005 | Type: | Redundancy Module |
| High Light: | analog interface module,plc power supply module |
||
Emerson DeltaV Power Supply Redundancy Module KJ2003X1-BA2 VE3005 12P2093X072 UK
Both NEW and USED are available.
Details:
Manufactured by EMERSON DELTAV
Alternate Part Number:
Introduction
This solution provides an upgrade to the RS3™ ControlFile with DeltaV™ controllers using the M-series
DeltaV Controller Interface for RS3 I/O. This solution incorporates RS3 I/O to be integrated into the DeltaV
architecture. The “heart” of the controller interface is a new DeltaV module that supports the serial I/O
communication capacity of the RS3 ControlFile. The DeltaV Controller Interface for RS3 I/O may be used
with both RS3 FlexTerm and MultiPoint I/O subsystems. Additionally, RS3 I/O support is integrated into the
DeltaV Explorer, Diagnostic, and Control Studio applications.
Product Description
The DeltaV Controller Interface for RS3 I/O is comprised of the RS3 I/O Interface Module, the RS3 Interface Carrier and the integration of RS3 I/O into DeltaV software.
RS3 I/O Interface Module.
The RS3 I/O Interface Module is a 2-wide module that provides serial communications between RS3 I/O and DeltaV controllers.
The module supports serial communications with both RS3 FlexTerm and MultiPoint I/O subsystems.
The RS3 I/O Interface Module features 64 serial communication channels providing serial communications to the installed RS3 I/O.
The RS3 I/O Interface Module, in effect, takes over the serial communication task of the ControlFile with the DeltaV controller managing the process.
The RS3 I/O Interface Module is designed with redundancy in mind.
One-to-one redundancy is built in. As with RS3, should you have an application that requires optimum system availability, redundancy is an option.
DeltaV MQ or MX Controller.
One DeltaV MQ controller (with DeltaV v12.3 or later firmware) or MX controller (with DeltaV v10.3) mounts on the carrier for a simplex installation, or two MQ or MX Controller mount for a redundant installation.
The MQ controllers can handle up to 750 DSTs while MX controller can handle up to 1500 DSTs.
RS3 I/O Interface Carrier.
The RS3 I/O Interface Carrier is a 19 inch rack mount device specifically designed to accommodate the RS3 I/O Interface.
The carrier will accommodate these DeltaV modules:
1.Two DeltaV MQ or MX Controller
2.Two DeltaV System Power Supplies
3.Two RS3 I/O Interface Modules
4.The RS3 I/O Interface Carrier has eight (8) multi-channel connectors to provide connection to RS3 I/O.
| Description | Model Number |
| 8 Channels 4-20 mA, HART Standard I/O Termination Block | VE4003S2B1 |
Redundant Standard I/O Termination Block | VE4033S2B1 |
| Fused I/O Termination Block | VE4003S2B2 |
| 4-wire I/O Termination Block | VE4003S2B3 |
| 16-Pin Mass Termination Block | VE4003S2B4 |
| 24-Pin Mass Termination Block | VE4003S2B5 |
| 16 Channels 4-20 mA, HART Standard I/O Termination Block | VE4003S2B6 |
| 4-wire I/O Termination Block 16 Channels 4-20 ma, HART, Plus Card | VE4003S2B7 |
| 16-Channel 2-Wire AI Terminal Block for Series 2 Plus | VE4003S2B9 |
| 16-Channel 4-Wire AI Terminal Block for Series 2 Plus | VE4003S2B10 |
| Redundant 16-Channel 2- & 4-Wire AI Terminal Block for Series 2 Plus | VE4033S2B10 |
| 8 Channels Thermocouple,mV Standard I/O Termination Block | VE4003S4B1 |
| Cold Junction Compensated (CJC) Termination Block | VE4003S5B1 |
Analog Input Card: 8 Channels RTD | VE4003S6B1 |
Isolated Input Card Isolated Input Terminal Block | VE4003S7B1 |
| Standard I/O Termination Block | VE4005S2B1 |
| Redundant Standard I/O Termination Block | VE4035S2B1 |
| Fused I/O Termination Block | VE4005S2B2 |
| 16-Pin Mass Termination Block | VE4005S2B3 |
| 16-Channel AO Terminal Block for Series 2 Plus | VE4005S2B4 |
| Redundant 16-Channel AO Terminal Block for Series 2 Plus | VE4035S2B4 |
| Standard I/O Termination Block | VE4001S2T1B1 |
| Fused I/O Termination Block | VE4001S2T1B2 |
| Standard I/O Termination Block | VE4001S2T2B1 |
| Redundant Standard I/O Termination Block | VE4031S2T2B1 |
| Fused I/O Termination Block | VE4001S2T2B2 |
| 16-Pin Mass Termination Block | VE4001S2T1B3 |
| 16-Pin Mass Termination Block | VE4001S2T2B3 |
| Standard Termination Block | VE4001S2T2B4 |
40-pin Mass Termination Block | VE4001S2T2B5 |
| Redundant32-Channel DI Terminal Block for Series 2 Plus | VE4031S2T2B6 |
40-pin DI Mass Termination Block for Series 2 Plus (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS) | VE4001S2T2B7 |
40-pin DI Mass Termination Block for Series 2 Plus including 2 x 16-channel DI Plus Mass Connection Boards* | VE4051S2T2B7 |
Redundant 40-pin DI Mass Termination Block for Series 2 Plus (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS) | VE4031S2T2B7 |
Redundant 40-pin DI Mass Termination Block for Series 2 Plus including 2 x 16-channel DI Plus Mass Connection Boards * | VE4081S2T2B7 |
| Standard I/O Termination Block | VE4001S3T1B1 |
| Fused I/O Termination Block | VE4001S3T1B2 |
| Standard I/O Termination Block | VE4001S3T2B1 |
| Fused I/O Termination Block | VE4001S3T2B2 |
| Discrete 32 Channel Terminal Block | VE4015 |
Discrete 32-Channel Terminal Block | VE4001S5T2B4 |
| 40-pin Mass Terminal Block | VE4001S5T2B5 |
| Standard I/O Termination Block | VE4002S1T1B1 |
| Fused I/O Termination Block | VE4002S1T1B2 |
| 16-Pin Mass Termination Block | VE4002S1T1B3 |
| Standard I/O Termination Block | VE4002S1T2B1 |
| Redundant Standard I/O Termination Block | VE4032S1T2B1 |
| Fused I/O Termination Block | VE4002S1T2B2 |
| 16-Pin Mass Termination Block | VE4002S1T2B3 |
| 10-Pin Mass Termination Block | VE4002S1T2B4 |
| Standard I/O Termination Block | VE4002S1T2B5 |
| 40-Pin Mass Termination Block | VE4002S1T2B6 |
40-pin DO Mass Termination Block for Series 2 Plus (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS) | VE4002S1T2B8 |
40-pin DO Mass Termination Block for Series 2 Plus including 4 x 8-channel DO Mass Connection Boards * | VE4052S1T2B8 |
Redundant 40-pin DO Mass Termination Block for Series 2 Plus (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS) | VE4032S1T2B8 |
Redundant 40-pin DO Mass Termination Block for Series 2 Plus including 4 x 8-channel DO Mass Connection Boards * | VE4082S1T2B8 |
| Standard I/O Termination Block | VE4002S2T1B1 |
| Fused I/O Termination Block | VE4002S2T1B2 |
Standard I/O Termination Block | VE4002S2T2B1 |
| Fused I/O Termination Block | VE4002S2T2B2 |
| 250V 2A Fuse for Fused Terminal Block; Box of 20 | KJ4010X1-BC1 |
Railbus Connection.
Additionally, the RS3 I/O Interface Carrier features a 37 pin railbus connection that may be used to interface with additional M-Series DeltaV I/O modules. Standard 37 pin DeltaV interface cables are used to connect the RS3 I/O Interface Carrier to traditional DeltaV I/O horizontal carriers. This feature means that you can expand your system with DeltaV I/O to fully utilize your DeltaV controller investment. DeltaV Programmable Serial Cards may also be used to connect PLCs and other serial devices that were connected to the RS3 ControlFile through the PLC FlexTerm.
