SGMSH-20DCA6C Industrial Sewing Machine Servo Motor 400V 2KW 5000RPM

Superb delivery a great product, perfect communication as well !! A++++

—— Carlos

Great deal. Fast shipping and good service.Recommended !!!!!!!!!

—— Gita

I'm Online Chat Now

SGMSH-20DCA6C Industrial Sewing Machine Servo Motor 400V 2KW 5000RPM

Large Image :  SGMSH-20DCA6C Industrial Sewing Machine Servo Motor 400V 2KW 5000RPM

Product Details:

Brand Name: Yaskawa
Model Number: SGMSH-20DCA6C

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Packaging Details: New in original box
Delivery Time: 2-3 work days
Payment Terms: TT West Union
Supply Ability: 100
Detailed Product Description
Place Of Origin: Japan Brand: Yaskawa
Model: SGMSH-20DCA6C Power: 2KW
Voltage: 40000V Max Speed: 5000RPM
Rated Speed: 3000RPM Series: SGMSH
High Light:

ac servo motor


electric servo motor






  1. Power : 2KW
  2. Voltage  : 400V
  3. Max Speed  : 5000RPM


  • AC Servo Motor
  • SGMSH Sigma II
  • Yaskawa Motor





Constant Torque (Lb-In) 56.4
Constant Torque (Nm) 6.36
Constant Torque (Oz-In) 902.4
Encoder Bit Resolution: 17 BIT
Encoder Type: Incremental
H x W x D: 3.94 in x 11.3 in x 3.94in
IP Rating IP67
kW 2KiloWatts
Mounting Type Flange Mount
Peak Torque (Lb-In) 169
Peak Torque (Nm) 19.1
Peak Torque (Oz-In) 2.074
Max Speed  5000
Shaft Seal Yes
Subcategory Servo




(1) Maximum Input Current


  • The instantaneous maximum output of SERVOPACK is approximately 3 times of the rated output for maximum for 3 seconds. Accordingly, select a molded-case circuit breaker whose breaking time is 5 seconds or more at 300% of SERVOPACK rated current. The general-purpose low-speed acting molded-case circuit breakers are applicable.


  • The power supply capacity per SERVOPACK when using a servomotor is described in 2.5.2 Molded-case Circuit Breaker and Fuse Capacity. Select a molded-case circuit breaker with the capacity larger than the effective load current (when using more than multiple SERVOPACK) calculated from the total power supply capacity.


  • The consumption of other controllers must be considered when selecting a molded-case circuit breaker



(2) Inrush Current


  •  Refer to 2.5.2 Molded-case Circuit Breaker and Fuse Capacity for SERVOPACK inrush current.


  •  The allowable inrush current for a low-speed acting molded-case circuit breaker is approximately 10 times of the rated current for 0.02 seconds.


  •  When turning ON multiple SERVOPACK simultaneously, select a molded-case circuit breaker with the allowable current for 20 ms larger than the total inrush current shown in 2.5.2 Molded-case Circuit Breaker and Fuse Capacity.








How easy is it to obtain SGMSH-20DCA6C?

The SGMSH-20DCA6C is no longer being produced, so supply is limited. Here at WTL, we are able locate and acquire difficult to find products. The time required to receive the part can vary, with an average of 5-7 business days.



What is the typical price for the SGMSH-20DCA6C?

Factors like availability and requirements necessary for delivery can impact pricing. That said, WTL offers a superior customer experience as well as competitive rates. For a quote on the SGMSH-20DCA6C, please contact us directly.



Does my purchase include a warranty? What if it’s damaged?

WTL provides a full 30-day warranty on each product sold, including a 30-day refund policy. If an extended warranty is purchased, the refund and exchange policies are also extended throughout the length of the warranty.



I'm an international company. Can we still do business together?

Of course! Our customers can be found across the globe. We can ship nearly anywhere in the world.



What payment options are available for purchasing the SGMSH-20DCA6C?

At WTL, we accept all major credit cards as well as company checks and wire transfers. Additionally, at the direction of our customers, we have also worked with escrow companies to complete payment transactions.



How do you ship your products?

Typically, we use major carriers, including UPS, FedEx, USPS, and DHL. If our customer has a particular shipping requirement, we will work with other carriers to ship the product.



Are repair services available from WtL?

We do provide repair services for the SGMSH-20DCA6C. Our knowledgeable engineering team will efficiently evaluate the part, diagnose the problem, and repair it within a good turn around time. Feel free to contact us today to discuss repair services options.



Can WTL assist me in managing the lifecycle of the SGMSH-20DCA6C?

Absolutely! Managing lifecycles of industrial parts and equipment is a service we excel at. Our specialty is tracking the lifecycle of industrial products from production to obsolescence. We phase out obsolete parts and try to introduce next-generation products when possible.



Do you provide assistance in moving large quantities of obsolete inventory?

Absolutely. Moving excess product is something we help companies with all of the time. More often than not, equipment that has reached the end of its life span is disposed of as scrap material. We strive to help companies obtain top market value for extra equipment they need to get rid of. GID can help with SGMSH-20DCA6C as well as a myriad of other products needing disposal services.
