2.2KW Ac Motor Frequency Converter / Emerson CT Inverter SP1404 Unidrive

Superb delivery a great product, perfect communication as well !! A++++

—— Carlos

Great deal. Fast shipping and good service.Recommended !!!!!!!!!

—— Gita

I'm Online Chat Now

2.2KW Ac Motor Frequency Converter / Emerson CT Inverter SP1404 Unidrive

Large Image :  2.2KW Ac Motor Frequency Converter / Emerson CT Inverter SP1404 Unidrive

Product Details:

Place of Origin: China
Brand Name: Emerson
Certification: CE
Model Number: SP1404

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: 450 USD
Packaging Details: New Original Box
Delivery Time: In Stock
Payment Terms: T/T / Paypal
Supply Ability: 50
Detailed Product Description
Product Name: Frequency Inverter Model: SP1404
Power: 2.2/3.0KW Voltage: 380-480V
Current: 5.8A Category: Control Techniques
High Light:

vfd frequency converter


variable frequency drive inverter

2.2KW Variable Frequency Inverter Emerson CT Inverter SP1404 Unidrive SP







The SP1404 is a 2.2kW, 5.8A, 380...480V AC inverter from the Unidrive SP range manufactured by Control Techniques. As an official Control Techniques distributor, Northern Industrial supply the whole range of Unidrive SP VSDs, including options to expand the functionality of the SP1404 VSD. Control Techniques design all of their variable frequency drives to be easy to install and commission, and the Unidrive SP is no different.




High Performance Motor Control



Take advantage of the several control modes included on the SP1404 and use your Unidrive SP to control induction, asynchronous servo and synchronous servo motors By using the keypad, you can configure your inverter to be operated in the following modes:

  • Servo - Precision, dynamic control supporting a wide range of rotary and linear motors
  • Closed Loop Vector - Ultimate precision control of induction motors offering full motor torque at zero speed
  • RFC Mode (Rotor Flux Control) - Superior dynamic performance and stability without a feedback device
  • Open Loop Vector - Good open loop motor performance with minimum configuration
  • Open Loop V/F Control - A simple control algorithm that is ideal for parallel motors
  • Regenerative - Active front end control mode for harmonic elimination and regeneration



Many Feedback Encoder Options



The Unidrive SP range has the hardware needed to connect to virtually any feedback encoder type, which enables the designer to select the most appropriate technology for the application.Incremental - Provides a good balance of cost and performance

  • SinCos - Offers increased position resolution for precision and low speed applications
  • SSI - Offers absolute position feedback
  • EnDat and HIPERFACE - These encoders transfer position data using a high-speed communications network, often combined with SinCos technology



Widest Range of System Integration Features



Select the level of integrated automation/motion control, connectivity and I/O that you need by using the plug-in option modules compatible with the Unidrive SP. SP1404 has room for three option modules, which you can select from the huge array of system integration features. Northern Industrial stock a wide range of option modules that are available for immediate despatch.

  • Input/Output options - Including SM-I/O 32, SM-I/O Plus, SM-I/O Lite
  • PLC/Motion functionality options - Including SM-Applications Lite V2, SM-Applications Plus, SM-EZMotion, SM-Register
  • Communications options - Including SM-EtherCAT, SM-LON, SM-Profibus DP, SM-Interbus, SM-DeviceNet, SM-Ethernet, SM-CANopen, SM-SERCOS, SM-CAN, SM-PROFINET
  • Feedback options - Including SM-Universal Encoder PLus, SM-Encoder Plus, SM-Resolver, SM-Encoder Output Plus



Simplify Set Up with a Smartcard



Commissioning new drives or backing up your parameter sets is made easy thanks to the Smartcard, which is provided with every Unidrive SP,including the SP14042.2kW inverter The Smartcard enables you to:

  • Store parameters and programs
  • Simplify drive maintenance and commissioning
  • Set sequential build of machines up quickly
  • Machine upgrades can be stored on a Smartcard and sent to the customer for installation



Other Models



SP1201 SP1202 SP1203 SP1204 SP2201 SP2202 SP2203 SP3201 SP3202 SP1401 SP1402 SP1403 SP1404
SP1405 SP1406 SP2401 SP2402 SP2403 SP3401 SP3402 SP3403 SP4401 SP4402 SP4403 SP5401 SP5402







WTL is not liable for any personal injury or property damage resulting from the use of this equipment. It is
buyer's responsibility as to the safe handling & operation of this equipment and to verify equipment is
compliance to their machinery.
