Emerson Module DELTAV KJ3201X1-BA1 VE4001S2T2B2 12P2535X042 Dry Contact Card
Quick detail:
KJ3201X1-BA1
DI, 8-Channel, 24 VDC, DryContact Series 2 Card
Both NEW and USED are available.
Alternate Part Number:
Power Specifications
| LocalBus power rating |
12 VDC at 150 mA |
|
Bussed field power rating
|
24VDC at 100 mA
|
| Field circuit rating |
24 VDC at 5 mA/channel
|
Environmental Specifications
| Ambient Temperature |
-40 to 70oC
|
| Shock |
10g ½ Sinewave for 11 msec |
| Vibration |
1mm Peak to Peak from 5 to 16Hz;
0.5g from 16 to 150Hz
|
| Airborne
Contaminants
|
ISA-S71.04
–1985 Airborne
Contaminants Class G3
|
| Relative Humidity |
5 to 95% Non-Condensing IP 20 Rating
|
|
Terminal block key position
|
B1 |
Note:
Refer to the product label for serial number and location and date of manufacture. Refer also to
the wiring diagram on the left side of the card.
Warning:
This product has specific instructions for installation, removal and operation in hazardous areas. Refer to document 12P2046 "DeltaV Scalable Process System Zone 2 Installation Instructions".Other installation instructions are available in the "Installing Your DeltaV Automation System" manua.
Removal and Insertion
Field power supplied to this device, either at the field terminal or as bussed field power through the carrier, must be removed before removing or connecting the device. This unit may be removed or inserted while system power is energized under the following conditions:
(Note Only one unit at a time may be removed with system power energized.)
•When used with KJ1501X1-BC1 System Dual DC/DC Power Supply operating on 24 VDC or 12 VDC input power. The primary circuit wiring inductance for input power must be less than 23 uH, or a certified supply with an open circuit voltage, Ui of 12.6 VDC and an Lo of less than 23 uH (including wire inductance).
An I/O loop assessment must be completed on all energy -limited nodes.
A terminal block fuse may NOT be removed with field power energized for non-sparking circuits.
Maintenance and Adjustment
This unit contains no user serviceable parts and should not be disassembled for any reason. Calibration is not required.
Similiar Models:
DELTAV KJ3201X1-BA1 VE4001S2T2B2 12P2535X042
DELTAV KJ3202X1-BA1 VE4002S1T2B2 12P2536X042
DELTAV KJ3203X1-BA1 VE4001S2T2B4 12P3270
DELTAV KJ3204X1-BA1 12P3275X022, VE4002S1T2B5
DELTAV KJ3206X1-BA1 VE4001S2T1B2 12P3901
DELTAV KJ3207X1-BA1 12P3902X012
DELTAV KJ3207X1-BB1 12P3903
DELTAV KJ3208X1-BA1 VE4002S1T1B1 12P3904
DELTAV KJ3221X1-BA1 12P2531X062 VE4005S2B2
DELTAV KJ3222X1-BA1 12P2532X072 VE4003S2B1
DELTAV KJ3223X1-BA1 12P2871X022
DELTAV KJ3223X1-EA1 12P2867X022
DELTAV KJ3224X1-EA1 12P4367X012
DELTAV KJ3231X1-BA1 VE4003S7B1 12P2957X042
DELTAV KJ3241X1-BA1 VE4009 12P0914X062
DELTAV KJ3242X1-BA1 12P2471X022 VE4017PO
DELTAV KJ3242X1-EA1 12P2574X032
DELTAV KJ3243X1-BA1 12P2830X022
DELTAV KJ3246X1-BA1 S-Series H1
DELTAV KJ3246X1-CA1 12P5540X022 H1
