DeltaV Power Supply KJ3002X1-BE1 12P0682X042 VE4005S2B2 Redundant Module

: Large Image : DeltaV Power Supply KJ3002X1-BE1 12P0682X042 VE4005S2B2 Redundant Module

Product Details:

Place of Origin:	U.S.A / Thailand / UK
Brand Name:	Emerson
Certification:	CE
Model Number:	KJ3002X1-BE1

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Contact us
Packaging Details:	New Original Box
Delivery Time:	2-3 work days
Payment Terms:	T/T / Paypal
Supply Ability:	50

Contact Now

Detailed Product Description

Model:	KJ3002X1-BE1	MODEL:	VE4005S2B2
PN:	12P0682X042	LocalBus Power Rating:	12 VDC At 150 MA
Bussed Field Power Rating:	24 VDC At 300 MA	Field Circuit Rating:	24 VDC At 23 MA
High Light:	analog interface module , diode redundancy module

Fisher Rosemount DeltaV Power Supply KJ3002X1-BE1 12P0682X042 VE4005S2B2

Power Specifications

LocalBus power rating:12 VDC at 150 mA

Bussed Field Power Rating:24 VDC at 300 mA

Field circuit rating:24 VDC at 23 mA

Environmental Specifications

Ambient Temperature:0 to 60℃

Shock:10g ½ Sinewave for 11 msec

Vibration:1mm Peak to Peak from 5 to 16Hz;0.5g from 16 to 150Hz

Airborne Contaminants:ISA-S71.04 –1985 Airborne Contaminants Class G3

Relative Humidity:5 to 95% Non-Condensing IP 20 Rating

Terminal block key position:A4

Quick Details:

Brand:	Fisher Rosemount
Condition:	New with factory packaging
Model:	KJ3002X1-BE1 12P0682X042 VE4005S2B2
Input Voltage (DC):	12 V-DC
Revision:	REV G
Shipping Weight:	0.85 lbs
Shipping Dimensions:	9.00 x 5.50 x 2.00 in
Category:	Controls

DeltaV Redundant Power Supply Module Models:

KJ3002X1-BE1 12P0682X042 VE4005S2B2	Analog Output 8-Channel 4-20mA HART Card
KJ3002X1-BG1 VE4003S5B1 12P1731X012	Thermocouple mV CARD
KJ3001X1-CB1 VE4002S1T2B5 12P1985X032	DO 32-Channel 24 VDC High-Side Card
KJ3002X1-BA1 VE4003S2 12P0680X122	Analog Input 8 Channel 4-20mA HART Card
KJ3001X1-BH1 VE4002S2T1 12P0558X152	DO 8-Ch 120/230 VAC Isolated
KJ3001X1-BJ1 VE4002S1T2B2 12P0555X122	DO 8-Channel 24 VDC High Side Card
KJ1501X1-BC1 VE5008 12P2186X012	System Dual DC Power Supply (DC/DC)
KJ1501X1-BA2 VE5001 12P0677X062	AC/DC System Power Supply
KJ3001X1-BH1 VE4002S2T1 12P0558X152	DO 8-Ch 120/230 VAC Isolated
KJ3001X1-BD1 VE4001S3T2B2 12P0552X122	Discrete Input 120VAC DRY CONTACT
KJ3001X1-BG1 VE4002S1T1 12P0557X152	DO 8-Channel 24 VDC Isolated Card
KJ4002X1-BB1 VE4055S2C0 12P1728X042	Right 8 Wide Vertical Carrier
KJ4002X1-BC2	4 WIDE VERTICAL CARRIER TOP
KJ4002X1-BE1 12P4048X012	Top Extender Cable
KJ4002X1-BF2 12P3866X012	Bottom Extender Cable
KJ4003X1-BE1 12P3839X022	Vertical Left Side Extender
KJ4003X1-BF1 12P3839X022	Vertical Left Side Extender
KJ4005X1-BA1 SE3051C0 12P4683	POWER/CONTROLLER CARRIER
KJ4010X1-BF1 12P0831X042	Local Bus Left Extension
KJ4010X1-BG1 12P0830X042	Local Bus Right Extension
KJ4101X1-BA1 12P1870X012	IS 8 Wide Carrier
KJ4101X1-BB1 12P1871	IS LOCAL BUS ISOLATOR CARRIER
KJ4101X1-BC1 12P1872X012	IS Power Supply Carrier
KJ4110X1-CA1 12P1873X012	IS Extender Right-hand CARRIER
KJ4110X1-CB1 12P1874X012	IS Extender Right-hand CARRIER
KL2101X1-BA1 12P4987X062	Charm I/O CARD
KL3002X1-BA1 12P4627X052	DO 24 VDC High-Side
KL3003X1-BA1 12P4632X082	DI 24 VDC Dry Contact
KL3021X1-BA1 12P4628X062	AI 4-20 mA HART
KL3022X1-BA1 12P4629X042	AO 4-20 mA HART
KL4101X1-BA1 12P4989	CHARM I/O CARRIER
KL4201X1-BA1 SE4601T07 12P4986X052	Charm Base plate
KL4502X1-BA1 12P4990X042	Charm Terminal
KJ4001X1-GG1 12P1812X022	Thermocouple Terminal Block
KJ4001X1-HB1 12P0830X072	Local Bus Right Extender
KJ4002X1-BA1 VE4055S1C0 12P1727X042	Left 8 Wide Vertical Carrier
KJ4001X1-CC1 12P0733X032	4 Wire TX Terminal Block
KJ1501X1-BK1 SE5009 12P4685	System Power Supply 24 DC/DC
KJ1700X1-BA1 VE6006 12P1710X012	Media Converter
KJ1710X1-BA1 VE6019 12P3305X	Single Port Fiber Switch
KJ3001X1-BK1 VE4002S2T2 12P0556X142	DO 8-Channel 120/230 VAC High Side
KJ3001X1-CA1 VE4001S2T2B4 12P1980X042	DI 32-Channel 24 VDC Dry Contact Card
KJ3002X1-BB1 12P0683X072	ANALOG OUTPUT 4-20mA
KJ3002X1-BC1 VE4003S1B2 12P0681X072	Analog Input Module Final Assy 4-20mA Card
KJ3003X1-BA1 12P0914	SERIAL INTERFACE CARD
KJ3003X1-EA1 12P0921X032	Interface Terminal Block

The DeltaV™ S-series controllers provide communication and control functions and integrate field devices and the other nodes on the control network. The SX, SQ and SD Plus controllers provide a choice to match the controller capacity to the requirements of the process. They also provide new ease of use features that eliminate mounting screws and accelerate cabinet assembly.
