200 Watt 200V AC Industrial Servo Motor Robot SGMPH-02A1A-YR32

Superb delivery a great product, perfect communication as well !! A++++

—— Carlos

Great deal. Fast shipping and good service.Recommended !!!!!!!!!

—— Gita

I'm Online Chat Now

200 Watt 200V AC Industrial Servo Motor Robot SGMPH-02A1A-YR32

Large Image :  200 Watt 200V AC Industrial Servo Motor Robot SGMPH-02A1A-YR32

Product Details:

Brand Name: Yaskawa
Model Number: SGMPH-02A1A-YR32

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Packaging Details: New in original box
Delivery Time: 2-3 work days
Payment Terms: T/T, Western Union
Supply Ability: 100
Detailed Product Description
Place Of Origin: Japan Brand: Yaskawa
Model: SGMPH-02A1A-YR32 Type: AC SERVO MOTOR
Power: 200W Volatge: 200V
Current: 2.0A Ins: B
High Light:

ewing machine servo motor

,

electric servo motor

Industrial Servo Motor YASKAWA ELECTRIC SGMPH-02A1A-YR32 AC Servo Motor Robot







Specifications

Categories Industrial Servo Motor
Brand Name: Yasakawa
Model Number: SGMPH-02A1A-YR32
Place Of Origin: Japan
MOQ: 1
Price: Negotiable
Payment Terms: T/T, Western Union
Supply Ability: 100
Delivery Time: 2-3 Work Days
Packaging Details: New In Original Box
Brand: Yasakawa
Model: SGMAH-A5AAA41
Palce Of Origin: Japan
Type: Servo Motor
Supply Voltage: 200W
Current: 2.0A
Ins: B
R/Min: 3000



















SIMILAR PRODUCTS



SGMGH-09ACA6C
SGMGH-09ACB61
SGMGH-09ACB6B
SGMGH-09PCA-AM14
SGMGH-12A2B2
SGMGH-12A2B21
SGMGH-13A2A-YR13
SGMGH-13A2A-YR23
SGMGH-13A2A-YR23A
SGMGH-13A2A-YR24
SGMGH-13ACA
SGMGH-13ACA21
SGMGH-13ACA61
SGMGH-13ACA6C
SGMGH-13DCA61
SGMGH-1AACA61
SGMGH-1EACA61
SGMGH-20A2B2C
SGMGH-20ABA6C
SGMGH-20ACA61
SGMGH-20ACA6B
SGMGH-20ACA6C
SGMGH-20ACB2C
SGMGH-20ACB61
SGMGH-20D2A21
SGMGH-30A2A-YR35
SGMGH-30A2A-YRA1
SGMGH-30A2B2C
SGMGH-30A2B6C
SGMGH-30ACA61
SGMGH-30ACB21
SGMGH-30ACB2C
SGMGH-30ACB61








Motor Drawing SGMPH 200V (Example)



Encoder Plug (Front View)
Encoder Connector
Pin Output Wire colour
1 0V (16 Bit Absolute Encoder) --
2 3,6V (16 Bit Absolute Encoder) --
3 Data + Blue
4 Data - Blue/White
5~7, 10~17 Free --
8 +5V (Power Supply) Red
9 0V (Power Supply) Black
Connector Case FG (Frame Ground) Shield Wire


Motor Plug 230V (Front View)
Motor Connector
Pin Output Wire Colour
1 Phase U Red
2 Phase V White
3 Phase W Blue
4 *Brake Terminal Black
5 *Brake Terminal Black
6 FG (Frame Ground) Green/Yellow



Encoder Cable for Servomotors SGMAH / SGMPH Part no: DP9325256-##G SGMAH-xxA, SGMAH-xxD, SGMPH-xxA and SGMP-xxD (##: cable length, 03 = 3m; 05 = 5m; 10 = 10m; 15 = 15m; 20 = 20m)
Terminal connection Encoder side                                 Terminal connection Servopack side
No. Description Colour No. Description Colour                    1 +5V (Power Supply) Pink
1 0V (Battery) Orange/White                                                 2 0V (Power Supply) Grey
2 3.6V (Battery) Orange                                                        3.6V (Battery) Green
3 DATA + Blue 3                                                                    4 0V (Battery) Yellow
4 DATA - Blue/White                                                              5 DATA + White
5~7 Free -
8 +5V (Power supply) Red (AWG22)
9 0V (Power supply) Black (AWG22)
10~17 Free - Connector case
Frame ground Shield wire Connect






1st + 2nd digits:
Rated Output (kW)
Code  01  02  04  08  15
Rated Output  0.1  0.2  0.4  0.75  1.5
3rd digit: Voltage A:200V,B:100V,D:400V

3rd digit: Voltage A:200V,B:100V,D:400V

5th digits: Design Revision Order IP67 water-proof specifications

4th digit: Serial Encoder
Code 1 4 A B
Remarks Standard
Standard Option
Specifications 16-bit absolute encoder 16-bit absolute encoder with super capacitor
13-bit incremental encoder 16-bit incremental encoder
The number of encoder pulses: 16384 P/Rev.
The number of encoder pulses: 2048 P/Rev.

6th digit: Shaft End
Code 2 4 6 8
Remarks Standard
Option Specifications Straight without key Straight with key Straight with key and tap Straight with tap

7th digit: Brake and Oil Seal
Code 1 B C D E S
Specifications Without options With 90-VDC brake With 24-VDC brake With oil seal and 90-VDC brake
With oil seal and 24-VDC brake With oil seal





Type SGMGH, 400 V
Ratings and specifications
Torque-speed charecteristics
Applied voltage 400 V
Servo motor model SGMGH- @ 05D@ 09D@ 13D@ 20D@ 30D@ 44D@ 55D@ 75D@ 1AD@ 1ED@
Rated output kW 0.45 0.85 1.3 1.8 2.9 4.4 5.5 7.5 11 15
Rated torque N·m 2.84 5.39 8.34 11.5 18.6 28.4 35.0 48.0 70.0 95.4
Instantaneous peak torque N·m 8.92 13.8 23.3 28.7 45.1 71.1 90.7 123 175 221
Rated current A (rms) 1.9 3.5 5.4 8.4 11.9 16.5 20.8 25.4 28.1 37.2
Instantaneous max. current A (rms) 5.5 8.5 14 20 28 40.5 55 65 70 85
Rated speed min-1 1500
Max. speed min-1 3000 2000
Torque constant N·m/A (rms) 1.64 1.65 1.68 1.46 1.66 1.82 1.74 2.0 2.56 2.64
Rotor moment of inertia (JM) kg·m2x10-4 7.24 13.9 20.5 31.7 46.0 67.5 89.0 125 281 315
Allowable load moment of inertia (JL) Multiple of (JM) 5
Rated power rate kW/s 11.2 20.9 33.8 41.5 75.3 120 137 184 174 289
Rated angular acceleration rad/s2 3930 3880 4060 3620 4050 4210 3930 3850 2490 3030
Applicable encoder Standard Incremental encoder (17 bits)
Option Absolute encoder (17 bits)
Holding brake moment of inertia J kg·m2x10-4 2.10 8.50 18.8 37.5 Basic specifications
Time rating Continuous
Insulation class Class F
Ambient temperature 0 to +40 °C
Ambient humidity 20 to 80% (non-condensing)
Vibration class 15 µm or below
Enclosure Totally-enclosed, self-cooled, IP67 (excluding shaft opening)
Vibration resistance Vibration acceleration
