Yaskawa Servopack Industrial Servo Drives 200V 3 Phease SGDM-60ADA

: Large Image : Yaskawa Servopack Industrial Servo Drives 200V 3 Phease SGDM-60ADA

Product Details:

Place of Origin:	Japan
Brand Name:	Yasakawa
Model Number:	SGDM-60ADA

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiable
Packaging Details:	New in original box
Delivery Time:	2-3 work days
Payment Terms:	T/T, Western Union
Supply Ability:	100

Contact Now

Detailed Product Description

Brand:	Yasakawa	Model:	SGDM-60ADA
Palce Of Origin:	Japan	Type:	Servopack
Power:	5.5KW	Input Current:	32A
Input Volatge:	200-230V	Input Frequency:	50/60HZ
Highlight:	electric servo drive , ac servo pack

Industrial Servo Drives Yaskawa Servopack 200V Model: SGDM-60ADA 5500W 3Phease

Quick Details

Brand Name:Yaskawa

Model Number:SGDM-60ADA

Input Voltage:200-230V

Input Current: 32A

Input Frequency:50/60HZ

Input PH : 3

Series : Sigma 2 (Σ-II Series)

Output Power : 5.5KW

Output Voltage: 0-230V

Output Current: 42.1A

Output Frequency:0-300Hz

Output PH :3

Temperture: 0-55℃

Place of Origin:Japan

Efficiency:IE 1

Similar Products

100W SGMAH-01AAA41+SGDM-01ADA
100W tape is made to move SGMAH-01AAA4C +SGDM-01ADA
200w SGMAH-02AAA41+SGDM-02ADA
200W tape is made to move SGMAH-02AAA4C +SGDM-02ADA
400W SGMAH-04AAA41+SGDM-04ADA
400W tape is made to move SGMAH-04AAA4C +SGDM-04ADA
750w SGMAH-08AAA41+SGDM-08ADA
750W tape braked SGMAH-08AAA4C+SGDM-08ADA

SGMGH type (1500RPM)
Capacity (W) Type
450 SGMGH-05ACA61+SGDM-05ADA
450W tape brakes SGMGH-05ACA6C +SGDM-05ADA
850W SGMGH-09ACA61+SGDM-10ADA
850W tape is made to move SGMGH-09ACA6C +SGDM-10ADA
1.3KW SGMGH-13ACA61+SGDM-15ADA
1.3KW tape is made to move SGMGH-13ACA6C +SGDM-15ADA
2KW SGMGH-20ACA61+SGDM-20ADA
2KW tape is made to move SGMGH-20ACA6C +SGDM-20ADA
3KW SGMGH-30ACA61+SGDM-30ADA
3KW tape is made to move SGMGH-30ACA6C +SGDM-30ADA

4.4K SGMGH-44ACA61+SGDM-50ADA
4.4KW tape brakes SGMGH-44ACA6C +SGDM-50ADA
5.5K SGMGH-55ACA61+SGDM-60ADA
5.5KW tape is made to move SGMGH-55ACA6C +SGDM-60ADA
7.5K SGMGH-75ACA61+SGDM-75ADA
7.5KW tape brakes SGMGH-75ACA6C +SGDM-75ADA
11KW SGMGH-1AACA61+SGDM-1AADA
11KW SGMGH-1AACA6C+SGDM-1AADA
15KW SGMGH-1EACA61+SGDM-1EADA
15KW SGMGH-1EACA6C+SGDM-1EADA
100W: SGMJV-01ADD6S+SGDV-R90A11A
SGMJV-01ADD6E+SGDV-R90A11A
200W: SGMJV-02ADD6S+SGDV-2R8A11A
SGMJV-02ADD6E+SGDV-2R8A11A
400W: SGMJV-04AAA61/C+SGDV-2R8A11A
SGMJV-04ADD6E/S
750W: SGMJV-08AAA61/C+SGDV-5R5A11A
SGMJV-08ADD6E/S
850W: SGMGV-09ADC61/C+SGDV-7R6A01A
1.3KW: SGMGV-13ADC61/C+SGDV-120A01A
2KW: SGMGV-20ADC61/C+SGDV-180A01A
3KW: SGMGV-30ADC61/C+SGDV-200A01A
4.4KW: SGMGV-44ADC61/C+SGDV-330A01A
5.5KW: SGMGV-55ADA61/C+SGDV-470A01A
7.5KW: SGMGV-75ADA61/C+SGDV-550A01A
11KW: SGMGV-1AADA61/C+SGDV-590A01A
15KW: SGMGV-1EADA61/C+SGDV-780A01A

Model follow-up control

A mechanical system is modeled to compensate for system delay and suppress vibrations when a machine has a low characteristic frequency. This function reduces the settling time of rigid machinery.

Vibration suppression control

The observer reduces the vibration, and high servo gain drive is achieved when a machine drive system is subject to vibrations. This function enhances the servo characteristics.

Mechanical resonance suppression filter

Resonance is suppressed by setting the vibration suppression filter in accordance with mechanical system resonance frequency when a high frequency resonance noise is made by the machine.

Torque reference filter

In the event that shaft resonance causes vibration in the servo system, the torque reference filter automatically suppresses resonance.

Speed observer control

Use of the speed observer provides smooth motion even at low speeds, and shorter position settling time.

Mode switch

To improve transient characteristics during motor acceleration and deceleration, the system can be switched between speed loop PI (proportional integral) and P (proportional) control, helping to prevent overshoot and undershoot.

Feed forward compensation

Feed forward compensation provides reduced positioning time.

Can be optimized with load conditions to shorten positioning time

Zero clamp operation

When speed control is used, drift may occur even with a speed command of 0V. The zero clamp function uses a position loop to stop servo-lock below a preset speed command.

SGDM -60ADA

Digital Operator (Type JUSP-OP02A-2)
