Product Details:
Payment & Shipping Terms:
|
| Brand: | Schneider | Model: | 140CPU53414A |
|---|---|---|---|
| Palce Of Origin: | FR | Type: | Quantum I/O |
| Series: | 140CPU | Module Format: | Standard |
| Clock Frequency: | 100 MHz | Weight: | 0.85KG |
| Highlight: | analog interface module,plc power supply module |
||
Redundant Power Supply Module Schneider 140CPU53414A Processor/Controller
Specifications |
|
| Manufacturer Series | 140CPU |
| Battery Backup | Yes |
| Maximum Inputs/Outputs | 158 (Input), 160 (Output) |
| Number of I/O | 32 (Distributed), 64 (Local), 64 (Remote) |
| Total Memory Available | 2972 (Internal) kB |
| Number of Outputs | 160 |
| Brand | Schneider Electric |
| Minimum Operating Temperature | 0°C |
| Maximum Operating Temperature | +60°C |
| Number of Communication Ports | 5 |
| For Use With | Modicon Quantum Automation Platform |
| Mounting Type | Rack Mount |
| Length | 290mm |
| Number of Inputs | 158 |
Main
| RANGE OF PRODUCT |
Modicon Quantum automation platform
|
|
|---|---|---|
| PRODUCT OR COMPONENT TYPE |
Processor
|
|
| SOFTWARE NAME |
Concept
ProWORX 32 |
|
| PROCESSOR NAME |
80486
|
|
| MATHEMATICAL COPROCESSOR |
With
|
Complementary
| CLOCK FREQUENCY |
100 MHz
|
|
|---|---|---|
| MEMORY DESCRIPTION |
Internal RAM 2972 kB
|
|
| EXACT TIME FOR 1 KINSTRUCTION |
0.1…0.5 ms LL984
|
|
| WATCHDOG TIMER |
250 ms
|
|
| CLOCK DRIFT |
+/-8 s/day at 32…140 °F (0…60 °C)
|
|
| I/O WORDS |
30 I/32 O distributed
64 I/64 O max local 64 I/64 O remote |
|
| I/O WORDS/NETWORK |
500 I/500 O distributed
|
|
| DROPS/NETWORK |
63 distributed
|
|
| NUMBER OF DROPS |
31 remote
|
|
| NUMBER OF NETWORK |
2 remote
3 distributed |
|
| BATTERY TYPE |
Lithium 10 µA 420 µA
|
|
| BATTERY CAPACITY |
1.2 Ah
|
|
| BATTERY LIFE |
10 yr
|
|
| SWITCH FUNCTION |
Key switch
|
|
| MARKING |
CE
|
|
| BUS CURRENT REQUIREMENT |
1250 mA
|
|
| MODULE FORMAT |
Standard
|
|
| PRODUCT WEIGHT |
1.87 lb(US) (0.85 kg)
|
Environment
| PROTECTIVE TREATMENT |
Conformal coating Humiseal 1A33
|
|
|---|---|---|
| PRODUCT CERTIFICATIONS |
CUL
FM Class 1 Division 2 |
|
| STANDARDS |
UL 508
CSA C22.2 No 142 |
|
| RESISTANCE TO ELECTROSTATIC DISCHARGE |
4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2 |
|
| RESISTANCE TO ELECTROMAGNETIC FIELDS |
9.14 V/yd (10 V/m) 80…2000 MHz conforming to IEC 801-3
|
|
| AMBIENT AIR TEMPERATURE FOR OPERATION |
32…140 °F (0…60 °C)
|
|
| AMBIENT AIR TEMPERATURE FOR STORAGE |
-40…185 °F (-40…85 °C)
|
|
| RELATIVE HUMIDITY |
95 % without condensation
|
|
| OPERATING ALTITUDE |
<= 16404.2 ft (5000 m)
|
Ordering and shipping details
| CATEGORY |
18150 – QUANTUM CONTROLLERS,HSBY,COMM.
|
|
|---|---|---|
| DISCOUNT SCHEDULE |
PC21
|
|
| GTIN |
00785901797364
|
|
| NBR. OF UNITS IN PKG. |
1
|
|
| PACKAGE WEIGHT(LBS) |
2.2000000000000002
|
|
| RETURNABILITY |
N
|
|
| COUNTRY OF ORIGIN |
FR
|
Offer Sustainability
| SUSTAINABLE OFFER STATUS |
Green Premium product
|
|
|---|---|---|
| ROHS (DATE CODE: YYWW) |
Compliant – since 1007 – Schneider Electric declaration of conformity Schneider Electric declaration of conformity
|
|
| REACH |
Reference not containing SVHC above the threshold
|
|
| PRODUCT ENVIRONMENTAL PROFILE |
Available
|
|
| PRODUCT END OF LIFE INSTRUCTIONS |
Available
|
Contractual warranty
| WARRANTY PERIOD |
18 months
|
|---|
OTHER SUPERIOR PRODUCTS
| Yasakawa Motor, Driver SG- | Mitsubishi Motor HC-,HA- |
| Westinghouse Modules 1C-,5X- | Emerson VE-,KJ- |
| Honeywell TC-,TK- | GE Modules IC - |
| Fanuc motor A0- | Yokogawa transmitter EJA- |
SHIPPING
The Schneider Electric / Modicon 140-CPU-534-14A is in stock and ready to ship from WTL. Same day shipping is available on most orders before 4 PM Eastern. If you have any questions about the shipping process call 86-13534205279.
CORE EXCHANGE
This product may qualify for our Core Exchange Program. Please contact us for additional information on exchanging your old part.
WARRANTY
Eagle PLC offers a 1 year warranty on all Schneider Electric / Modicon products including the 140-CPU-534-14A.
