Product Details:
Payment & Shipping Terms:
|
| Brand: | Yaskawa | Model: | SGMGV-20A3A2C |
|---|---|---|---|
| Place Of Origin: | Japan | Type: | AC SERVO MOTOR |
| Power: | 1.8 KiloWatts | Series: | SGMGV |
| IP Rating: | IP67 | Rated Speed: | 1,500 RPM |
| Highlight: | ac servo motor,electric servo motor |
||
YASKAWA ELECTRIC Servo Motor 3000 RPM SGMGV-20A3A2C 1.8 KiloWatts 28.7N.m
| Manufacturer: | Yaskawa |
| Series: | Motors |
| Weight: | Ask |
| Approvals: | UL, CE, cUL Recognized |
| Brake: | Yes |
| Brand: | Yaskawa |
| Constant Torque (Nm): | 11.5 |
| Constant Torque (Oz-In): | 1,628.6 |
| Encoder Bit Resolution: | 20 BIT |
| Encoder Type: | Absolute |
| H x W x D: | 9.02 in x 5.12 in x 5.12 in |
| IP Rating: | IP67 |
| kW: | 1.8 KiloWatts |
| Max Speed: | 3,000 RPM |
| Mounting Type: | Flange Mount |
| Peak Torque (Nm): | 28.7 |
| Peak Torque (Oz-In): | 4,064.3 |
| Rated Speed: | 1,500 RPM |
| Series: | SGMGV |
| Servomotor Type: | Rotary |
| Shaft Seal: | No |
| Subcategory: | Servo |
| Voltage: | 200 VAC |
