HC-MFS23G2 Compact High Speed Industrial Servo Motor 400V SRVMTR 7KW Mitsubishi

Mitsubishi HC-MFS23G2 AC Servo Motor 400V SRVMTR 7KW Industrial Servo Motor


HC-MFS23G2 Description

HC-MFS23G2 Key Features

• Ultra-Low Inertia Design: Extremely low rotor inertia (0.0000088 kg·m²) for maximum acceleration/deceleration performance, perfect for high-frequency, short-cycle motion tasks.
• High-Resolution Encoder: 17-bit incremental optical encoder (131,072 ppr) delivers precise feedback, enabling sub-micron positioning accuracy and stable low-speed operation.
• Balanced Torque-Speed Performance: Rated torque 0.64 Nm, maximum peak torque 1.9 Nm (300% of rated); rated speed 3000 rpm, maximum speed 4500 rpm for a wide operating range.
• Robust Environmental Protection: IP55 rating (body) resists dust, oil mist, and low-pressure water jets, suitable for harsh industrial environments.
• Compact & Lightweight: Slim 60×60mm flange, lightweight build (approx. 1.0 kg) saves installation space for compact machinery and robotic end-effectors.
• Maintenance-Free Operation: Brushless design eliminates brush wear; natural air cooling requires no fan maintenance, ensuring long service life.
• Standardized Mechanical Interface: Straight keyed shaft for secure torque transmission; dedicated power/encoder connectors for quick, reliable wiring.
• Wide Compatibility: Fully matched with Mitsubishi MR-J2S series amplifiers (MR-J2S-20A / MR-J2S-20B), supporting auto-tuning and vibration suppression functions.
• Global Compliance: CE, UL, and RoHS certified for worldwide industrial deployment.

HC-MFS23G2 Materials & Applications

Materials

• Stator & Rotor Core: High-grade non-oriented silicon steel laminations, optimized for minimal iron loss, high magnetic efficiency, and smooth torque output.
• Rotor Magnets: High-performance neodymium-iron-boron (NdFeB) permanent magnets, providing stable flux density and consistent torque across speed ranges.
• Housing & Flange: Die-cast aluminum alloy, lightweight with excellent thermal conductivity for efficient natural heat dissipation and corrosion resistance.
• Shaft: High-strength hardened alloy steel, precision ground with a keyway for secure coupling, ensuring concentricity and wear resistance.
• Bearings: High-precision, low-friction industrial ball bearings, designed for high-speed operation and extended service life under continuous duty.
• Internal Wiring & Encoder: High-temperature-resistant insulated wiring; sealed 17-bit incremental optical encoder for dust and moisture protection.
• Connectors: Industrial-grade plastic and metal connectors, IP55-rated, ensuring stable power and signal connections.

Typical Applications

• SMT & Semiconductor Equipment: Pick-and-place machines, PCB assembly, chip handlers, and precision testing equipment requiring ultra-fast positioning.
• Small Robotics: Miniature robots, SCARA robot arms, and end-effectors for high-speed assembly and handling.
• Packaging Machinery: Labeling machines, small cartoners, filling machines, and high-speed packaging lines.
• Printing & Textile: High-speed printers, labelers, winding machines, and embroidery equipment.
• Precision Automation: X-Y positioning tables, small CNC machines, engravers, and linear actuators for high-precision motion.
• General Industrial: Conveyors, small feeders, inserters, and assembly lines requiring rapid, repeatable motion cycles.

HC-MFS23G2 Important Parameters
