HG-KR053BJ Original Electric Mitsubishi Industrial Servo Motor 2000 RPM

                 Mitsubishi Industrial Servo Motor HC-SFS301B New Original Industrial Servo Motor Electric Motor

The ​​Mitsubishi HG-KR053BJ​​ is a compact, high-performance AC servo motor designed for precision automation applications. As part of Mitsubishi's HG-KR series, this motor delivers exceptional torque-to-size ratio and fast response characteristics, making it ideal for space-constrained industrial applications requiring precise motion control.

​​Product Overview:​​

The HG-KR053BJ combines Mitsubishi's advanced servo technology with robust construction, featuring high torque output in a compact NEMA 17 (40mm) frame. This motor is optimized for high-speed operation and precise positioning in various automation systems.

​​Key Features:​​

✅ ​​Compact High-Torque Design​​

• Ultra-compact NEMA 17 (40mm) frame size
• High torque output of 0.16N·m (23 oz-in)
• Lightweight design (0.45kg) for easy integration

✅ ​​High-Speed Performance​​

• Maximum speed of 6000rpm
• Smooth operation across the entire speed range
• Low vibration and noise characteristics

✅ ​​Precision Motion Control​​

• 17-bit absolute encoder for precise position feedback
• Low inertia rotor (0.0034kg·m²) for high acceleration
• Fast response time for dynamic applications

✅ ​​Robust Construction​​

• High-quality aluminum housing with protective coating
• Sealed design for reliable operation in industrial environments
• IP67 protection rating (with shaft seal)

✅ ​​Seamless System Integration​​

• Perfect compatibility with Mitsubishi MELSERVO-J4 servo amplifiers
• Support for SSCNETIII/H high-speed communication
• Easy setup with Mitsubishi digital operator

​​Technical Specifications:​​

​​Product Details:​​

​​Mechanical Construction:​​

• Precision-machined aluminum housing for lightweight strength
• High-quality ball bearings for smooth rotation (rated for 20,000+ hours)
• Sealed design with optional shaft seal for IP67 protection
• Standard keyway and set screw shaft configuration

​​Electrical Characteristics:​​

• Optimized winding design for high efficiency (90%+)
• Low inductance for fast response time
• Phase-to-phase insulation resistance: 100MΩ min. (500VDC)
• Built-in temperature sensor for overload protection

​​Compatibility:​​

• Designed specifically for Mitsubishi MELSERVO-J4 servo amplifiers
• Supports advanced digital control algorithms
• Compatible with Mitsubishi's digital operator for easy setup

​​Applications:​​

• ​​Small Parts Assembly Systems​​
• ​​Precision Positioning Equipment​​
• ​​Medical Device Automation​​
• ​​Laboratory Instrumentation​​
• ​​Electronic Component Handling​​
• ​​Semiconductor Equipment​​
• ​​Packaging Machinery​​
• ​​Textile Machinery​​

​​Why Choose HG-KR053BJ?​​

✔ ​​Ultra-Compact Design​​ - Delivers impressive performance in a tiny footprint
✔ ​​High-Speed Capability​​ - Ideal for applications requiring rapid motion
✔ ​​Precision Engineering​​ - Perfect for applications needing accurate positioning
✔ ​​Reliable Operation​​ - Built for continuous duty in demanding environments
✔ ​​Easy Integration​​ - Seamless compatibility with Mitsubishi's servo system

​​Ordering Information:​​

​​Part Number:​​ HG-KR053BJ
​​Standard Accessories:​​

• Operation manual
• Connection diagram
• Mounting hardware kit

​​Packaging:​​ Individual anti-static packaging
​​Availability:​​ Standard lead time: 2-3 weeks

​​Note:​​ For complete technical documentation, including:

• Detailed wiring diagrams
• Performance curves
• Dimensional drawings
• Recommended amplifier specifications

Please consult the official datasheet or contact our technical support team.

​​Recommended System Components:​​

This comprehensive product description provides all necessary technical details while highlighting the HG-KR053BJ's key advantages for precision automation applications. The format is suitable for:

• Industrial equipment catalogs
• Technical specification sheets
• E-commerce product pages for B2B sales
• Engineering procurement documents

• Estimated Lead Time: 7-10 Working Days

• Manufacturer: Mitsubishi Electric

• HG-KR053B

• Series name : MELSERVO-J4 series

• Command interface : CC-Link IE field network interface : SSCNETⅢ / H interface , 2-axis integrated SSCNETⅢ / H interface , 3-axis integrated SSCNETⅢ / H interface , general-purpose interface

• Voltage class : 200V

• Rotary servo motor form name : HG-KR053B

• Corresponding servo amplifier :

• CC-Link IE , field network , interface : J4-10GF-MR , MR-J4-10GF-RJ , MR-J4-10B-RJ010

• SSCNETⅢ / H , interface : J4-10B-MR , MR-J4-10B-RJ

• 2-axis integrated SSCNETⅢ / H interface : J4W2-22B-MR , MR-J4W2-44B

• 3-axis integrated SSCNETⅢ / H interface : J4W3-222B-MR , MR-J4W3-444B

• General-purpose interface : J4-10A-MR , MR-J4-10A-RJ

• Power supply capacity * 1 [KVA] : 0.3

• Continuous characteristics : Rated output [KW] : 0.05

• Continuous characteristics : Rated torque (Note 3) [N · m] : 0.16

• Maximum torque [N · m] : 0.56

• Declared engine speed [R / min] : 3000

• Maximum rotational speed [R / min] : 6000

• Instantaneous allowable rotation speed [R / min] : 6900

• Power rate at the time of continuous rating torque [KW / s] : 5.37

• Rated current [A] : 0.9

• Maximum current [A] : 3.2

• The regenerative braking frequency * 2 : MR-J4- [Times / min] : (Note 4)

• The regenerative braking frequency * 2 : MR-J4W_- [Times / min] : 2500

• Moment of inertia J [× 10 -4Kg · M 2] : 0.0472

• Recommended load inertia moment ratio (Note 1) : 17 times or less

• Speed ​​and position detector : Absolute position incremental shared 22-bit encoder (resolution per rotation servo motor 1: 4194304 pulses / rev)

• Oil seal : None

• Thermal class : 130 (B)

• Construction : All enclosed self cold (protection rating: IP65) (Note 2)

• Environmental conditions * 3 : Ambient temperature : Operation: 0 ° C ~ 40 ° C (no freezing), storage: -15 ° C ~ 70 ° C (no freezing)

• Environmental conditions * 3 : Ambient humidity : Operation: 80% RH or less (non-condensing), storage: 90% RH or less (non-condensing)

• Environmental conditions * 3 : atmosphere : Indoors (no direct sunlight), that there is no corrosive gas, flammable gas, oil mist, dust and dirt

• Environmental conditions * 3 : elevation : Above sea level 2000 m or less

• Environmental conditions * 3 : Vibration resistance * 4 : X: 49 M / S 2 Y: 49 M / S 2

• Vibration class : V10 * 6

• Overseas Compliance : The correspondence to the international standards and laws, Standards Compliant pageplease refer to.

• Axis of the allowable load * 5 : L [Mm] : twenty five

• Axis of the allowable load * 5 : radial [N] : 88

• Axis of the allowable load * 5 : Thrust [N] : 59

• mass [kg] : 0.54

• Shipping Weight: 2 Kg
