Mitsubishi HC-KFS13BK AC Servo Motor 3-PHASE 105V 0.7A 100W
HC-KFS13BK Overview
The Mitsubishi HC-KFS13BK is a compact, high-performance servo motor from Mitsubishi Electric’s HC-KFS series, designed for precision motion control in industrial automation applications. Featuring a built-in brake and high torque density, this motor is ideal for applications requiring quick stopping, vertical load holding, and accurate positioning. It is compatible with Mitsubishi’s MR-J4 series servo amplifiers, ensuring seamless integration into advanced motion control systems.
HC-KFS13BK Key Features
-
High Torque & Compact Design – Optimized for space-constrained installations.
-
Built-in Electromagnetic Brake – Ensures safety in vertical or emergency-stop applications.
-
Smooth Operation – Low vibration and noise for high-precision tasks.
-
High-Speed Response – Ideal for dynamic motion control.
-
Compatible with SSCNET III/H – Enables high-speed communication with Mitsubishi PLCs.
HC-KFS13BK Specifications
|
Category
|
Details
|
| Model |
HC-KFS13BK |
| Series |
HC-KFS (Servo Motor with Brake) |
| Motor Type |
AC Synchronous Servo Motor |
| Rated Output |
100W |
| Rated Torque |
0.32 Nm |
| Max. Torque |
0.96 Nm |
| Rated Speed |
3000 rpm |
| Max. Speed |
5000 rpm |
| Brake Type |
Electromagnetic (built-in) |
| Encoder |
17-bit (131,072 pulses/rev) |
| Protection Class |
IP65 (Shaft IP20) |
| Cooling Method |
Natural Convection (Fanless) |
| Weight |
1.5 kg |
HC-KFS13BK Materials & Construction
-
Frame: Aluminum alloy housing for lightweight durability.
-
Shaft: Stainless steel with keyway for secure coupling.
-
Insulation: Class F (155°C) for high thermal resistance.
-
Sealing: IP65-rated (dustproof & water-resistant).
HC-KFS13BK Applications
-
Industrial Robots (Pick-and-place, assembly)
-
CNC Machinery (Lathes, milling machines)
-
Packaging Equipment (Conveyors, filling machines)
-
Medical Devices (Precision positioning systems)
-
Semiconductor Manufacturing (Wafer handling)
HC-KFS13BK Electrical & Mechanical Parameters (Table Format)
|
Parameter
|
Value
|
Unit
|
| Rated Voltage |
200V AC (3-phase) |
V |
| Rated Current |
0.8 A |
A |
| Torque Constant |
0.40 Nm/A |
Nm/A |
| Rotor Inertia |
0.067 × 10⁻⁴ kg·m² |
kg·m² |
| Backlash |
≤1 arcmin |
- |
| Ambient Temperature |
0°C to +40°C |
°C |
| Vibration Resistance |
5.9 m/s² (10–55 Hz) |
- |
| Certifications |
CE, RoHS, UL |
- |
HC-KFS13BK Compatible Drivers & Controllers
-
Servo Amplifiers: MR-J4-10A, MR-J4-20A (Mitsubishi)
-
PLCs: MELSEC iQ-R, Q Series (via SSCNET III/H)
Note: For installation and wiring details, refer to the Mitsubishi HC-KFS13BK Instruction Manual.
