| Brand: | MITSUBISHI | Modenl Number: | Q06UDHCPU |
|---|---|---|---|
| Country Of Origin: | Japan | Program Capacity: | 60 K Steps |
| Basic Operation Processing Speed (LD Instruction): | 0.12 μs | Input: | 100 To 240 V AC |
| Output: | 5 V DC/3 A | Type: | Redundant Power Supply Module |
| Highlight: | analog interface module,diode redundancy module |
||
Q06UDHCPU Universal model Redundant Power Supply Module Mitsubishi 8192 points 60 k steps
The Mitsubishi Q06UDHCPU is a high-performance, general-purpose CPU module belonging to the renowned Mitsubishi Q Series PLC family. It is engineered for complex industrial automation systems that demand substantial processing power, versatile connectivity, and robust control capabilities. This module serves as the central brain for automation applications, capable of handling large-scale I/O points, executing sophisticated control algorithms, and seamlessly integrating with various networks and specialized modules for tasks ranging from process control to motion positioning
High-Speed Processing: Boasts an exceptionally fast basic processing speed, with a LD instruction execution time of 1.9 ns and a MOV instruction time of 3.9 ns, enabling rapid control cycle times and efficient handling of large, complex programs
Large Memory Capacity: Offers a program capacity of 60K steps and a program memory capacity of 240 KB, providing ample space for extensive control logic and data handling
.
Multi-CPU and High-Speed Communication: Supports a multi-CPU configuration on a single baseplate, allowing different CPU types (e.g., motion, process) to work together. It features high-speed inter-CPU communication (with a cycle time as low as 0.88ms), facilitating synchronized control in complex machines
.
Versatile Connectivity and Data Handling: Equipped with multiple built-in communication ports, including USB, Ethernet (00BASE-TX/10BASE-T), and a storage card interface (supporting SD/SDHC cards and extension SRAM cards)
. T•Advanced Control Functions: Supports a wide range of control capabilities, including positioning control (up to 16 axes with interpolation like linear, circular, and helical), process control, and data logging
. It•Material: The Q06UDHCPU is constructed from industrial-grade electronic components on printed circuit boards (PCBs), housed within a robust casing typically made from high-quality engineering plastics and metal alloys to ensure durability, efficient heat dissipation, and protection against harsh industrial environments like dust, vibration, and electromagnetic interference (EMI)
.
Primary Applications: This CPU is suited for a wide array of demanding automation scenarios, including:
Factory Automation: Machine control, assembly lines, and centralized control systems for manufacturing plants
.
Intelligent Building Management: Control systems for building automation, such as energy management, lighting control, and HVAC systems
.Process Control: Monitoring and controlling processes in industries like water treatment, chemicals, and food & beverage.
Packaging and Material Handling: High-speed packaging machinery and complex conveyor system control.
Parking Automation: Serves as the core controller in intelligent parking garage management systems, handling vehicle entry/exit logic, space monitoring via sensors, and barrier control
.
The key technical specifications for the Mitsubishi Q06UDHCPU are summarized in the table below.
|
Parameter Category |
Specification |
|---|---|
| Model Number |
Q06UDHCPU
|
| Program Capacity |
60 K steps
|
| Program Memory Capacity |
240 KB
|
| I/O Points (Controlable) |
4096 points
|
| I/O Software Points (Usable) |
8192 points (X/Y0~1FFF)
|
| Processing Speed |
LD Instruction: 1.9 ns; MOV Instruction: 3.9 ns |
| Built-in Communication Ports |
USB, Ethernet (10BASE-T/100BASE-TX)
|
| Storage Card Interface |
SD/SDHC Card, Extension SRAM Card
|
| Multi-CPU High-Speed Comm. |
Supported (Cycle time: 0.88 ms)
|
| Positioning Control Axes |
Up to 16 axes
|
| Interpolation Functions |
Linear (up to 4 axes), Circular (2 axes), Helical (3 axes) |
| Dimensions (H × W × D) |
98 mm × 27.4 mm × 115 mm
|
| Weight |
Approx. 0.2 kg
|
| DC5V Consumption Current |
0.33 A (CPU module itself)
|
| Primary Application Industries |
Factory Automation, Process Control, Building Management, Packaging |
