Mitsubishi Q68ADI Universal Model Redundant Power Supply Module 100 To 240 V AC

Mitsubishi Q68ADI Universal Model Redundant Power Supply Module 100 To 240 V AC

Product Details:

Place of Origin: Japan
Brand Name: MITSUBISHI
Certification: CE
Model Number: Q68ADI

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Contact
Packaging Details: new and original
Delivery Time: 5-7 days
Payment Terms: T/T, Western Union,paypal
Supply Ability: 100
Get Best Price Contact Now

Detail Information
Brand: MITSUBISHI Modenl Number: Q68ADI
Country Of Origin: Japan Program Capacity: 8 K Steps
Basic Operation Processing Speed (LD Instruction): 0.12 μs Input: 100 To 240 V AC
Output: 5 V DC/3 A Type: Redundant Power Supply Module
Highlight:

plc power supply module

,

diode redundancy module

Product Description

Mitsubishi Q68ADI Universal model Redundant Power Supply Module



Q68ADI  Description​​

The Mitsubishi Q68ADI is a high-performance analog-to-digital converter module designed for the MELSEC Q series of programmable logic controllers (PLCs). This module is responsible for receiving standard analog voltage or current signals (e.g., 0-10V, 4-20mA) from field sensors and transmitters, converting them into high-resolution digital values, and making this data available to the CPU for processing and control logic. It is an essential component for industrial automation systems requiring precise monitoring of process variables such as temperature, pressure, flow, and level.

​​Q68ADI Features​​

  1. 1.
    ​​High Channel Density:​​ Provides 8 analog input channels in a single module slot, optimizing control cabinet space and reducing system cost per channel.
  2. 2.
    ​​High Resolution:​​ Supports 16-bit high resolution (1/32000 scale), enabling highly accurate measurement of analog signals for precise control applications.
  3. 3.
    ​​Flexible Input Range:​​ Each channel can be individually configured for a wide range of analog inputs, including 0-10V, 0-5V, 1-5V, -10 to +10V DC, 0-20mA, and 4-20mA.
  4. 4.
    ​​Easy Configuration:​​ Settings such as input range selection, scaling, and alarm values are easily configured using the GX Works2 software, eliminating the need for complicated hardware switches.
  5. 5.
    ​​Online Module Change:​​ Supports online module replacement (requires a special function module bus board), allowing for maintenance and replacement without stopping the operating system, which is critical for high-availability processes.
  6. 6.
    ​​Diagnostic Functions:​​ Includes error detection functions such as disconnection detection for the 4-20mA range and alarm output for set values, aiding in quick troubleshooting and system reliability.

​​Q68ADI  Material & Applications​​

  • •
    ​​Material:​​ The module is constructed with a robust metal casing (for EMI shielding and durability) and a high-quality plastic front cover. The terminal block is typically heat-resistant thermoplastic.
  • •
    ​​Primary Applications:​​
    • •
      ​​Process Control:​​ Monitoring and control in chemical, pharmaceutical, and food & beverage industries.
    • •
      ​​Factory Automation:​​ Reading signals from analog sensors for position, force, or pressure in automotive and machinery manufacturing.
    • •
      ​​Environmental Monitoring:​​ Measuring variables like temperature, humidity, and water quality.
    • •
      ​​HVAC Systems:​​ Controlling temperature and pressure in building management systems.

​​Q68ADI  Important Parameters​​

The key specifications for the Mitsubishi Q68ADI module are summarized in the table below.
Parameter
Specification
​​Module Model​​
Q68ADI
​​Number of Channels​​
8 channels
​​Input Signal Range​​
Selectable per channel: DC 0-10V, 0-5V, 1-5V, -10 to +10V, 0-20mA, 4-20mA
​​Digital Resolution​​
16-bit binary (1/32000 resolution)
​​Accuracy​​
±0.1% (of full scale) for voltage inputs; ±0.2% (of full scale) for current inputs
​​Conversion Speed​​
80 µs/channel (Conversion is performed sequentially for all 8 channels)
​​Isolation Method​​
Photocoupler isolation between analog circuits and the PLC's internal bus
​​External Wiring​​
38-point terminal block (Uses the Q6TE-18TN terminal)
​​Power Consumption​​
5V DC, 0.36A (supplied from the main base unit)
​​Compatible PLC Series​​
MELSEC-Q Series
​​Configuration Software​​
GX Works2



性能仕様

入力仕様
アナログ入力点数
アナログ入力 電流
デジタル出力
入出力特性,分解能 入力レンジ
電流入力 0～20mA
4～20mA
ユーザレンジ設定
精度(デジタル出力値の最大値に対する精度) 周囲温度:25±5℃
周囲温度:0～55℃
A/D変換速度
絶対最大入力 電流
共通仕様
絶縁方式
絶縁耐圧
絶縁抵抗
外部配線接続方式
入出力占有点数
DC5V内部消費電流
外形寸法 高さ(H)
幅(W)
奥行き(D)
質量

8点(8チャンネル)
DC0～20mA(入力抵抗値:250Ω)
通常分解能モード:-4096～+4095
高分解能モード:-12288～+12287,-16384～+16383
デジタル出力値(最大分解能)
通常分解能モード:0～4000(5µA)
高分解能モード:0～12000(1.66µA)
通常分解能モード:0～4000(4µA)
高分解能モード:0～12000(1.33µA)
通常分解能モード:-4000～4000(1.37µA)
高分解能モード:-12000～12000(1.33µA)
±0.1％以内
温度ドリフト補正あり:±0.3％以内
温度ドリフト補正なし:±0.4％以内
80µs／チャンネル
(温度ドリフト補正ありのとき,使用チャンネル数にかかわらず160µs加算した時間になります.)
±30mA

入出力端子とシーケンサ電源間:フォトカプラ絶縁
アナログ入力チャンネル間:非絶縁
入出力端子とシーケンサ電源間:AC500V　1分間
入出力端子とシーケンサ電源間:DC500V　20MΩ以上
18点ネジ端子台(M3ネジ)
16点(I/O割付:インテリ 16点)
0.64A
98mm
27.4mm
90mm
0.19kg
