Q68AD-G Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC

Q68AD-G Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC

Product Details:

Place of Origin: Japan
Brand Name: MITSUBISHI
Certification: CE
Model Number: Q68AD-G

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Contact
Packaging Details: new and original
Delivery Time: 5-7 days
Payment Terms: T/T, Western Union,paypal
Supply Ability: 100
Get Best Price Contact Now

Detail Information
Brand: MITSUBISHI Modenl Number: Q68AD-G
Country Of Origin: Japan Program Capacity: 8 K Steps
Basic Operation Processing Speed (LD Instruction): 0.12 μs Input: 100 To 240 V AC
Output: 5 V DC/3 A Type: Redundant Power Supply Module
Highlight:

analog interface module

,

diode redundancy module

Product Description

Q68AD-G Mitsubishi Universal model Redundant Power Supply Module



Q68AD-G Description

The Mitsubishi Q68AD-G is a high-performance analog-to-digital (A/D) conversion module designed for the MELSEC Q Series of Programmable Logic Controllers (PLCs). This module is engineered to receive analog voltage or current signals from field instruments (such as sensors and transmitters) and convert them into high-resolution digital values for processing within the CPU. It is a critical component for industrial automation applications requiring precise monitoring and control of process variables like temperature, pressure, flow, and level. The Q68AD-G offers high accuracy, fast conversion speeds, and robust reliability, making it suitable for complex and demanding industrial environments.

Q68AD-G Features

  1. 1.
    ​​High Channel Density:​​ Provides 8 analog input channels in a single module slot, saving space in the PLC base unit.
  2. 2.
    ​​High Resolution:​​ Offers a exceptional resolution of 1/60,000, ensuring highly accurate digital representation of analog signals for precise control.
  3. 3.
    ​​Flexible Input Ranges:​​ Supports a wide selection of analog input ranges, including:
    • •
      Voltage: -10 to +10 V DC, 0 to 5 V DC, 1 to 5 V DC, etc.
    • •
      Current: 0 to 20 mA DC, 4 to 20 mA DC (with built込 fault detection for 4-20mA signals).
  4. 4.
    ​​Fast Conversion Speed:​​ Achieves a high-speed conversion of 80 µs per channel, allowing for rapid system response to process changes.
  5. 5.
    ​​Built-in Functions:​​ Includes advanced functions such as scaling, input signal error detection (wire break, overrange/underrange), and sampling processing, simplifying program logic.
  6. 6.
    ​​Easy Setup:​​ Can be easily configured using GX Works2, Mitsubishi's integrated engineering software, for setting parameters without complex programming.

Q68AD-G Material & Applications

  • •
    ​​Material:​​ The module is constructed with a robust plastic housing and a metal connector for durability. The internal circuitry uses high-quality electronic components to ensure stable operation in industrial conditions.
  • •
    ​​Primary Applications:​​ Widely used in various industries for process automation, including:
    • •
      ​​Factory Automation:​​ Monitoring motor speeds, pressure in hydraulic/pneumatic systems.
    • •
      ​​Environmental Control:​​ Measuring temperature and humidity in HVAC systems.
    • •
      ​​Water and Wastewater Treatment:​​ Monitoring pH levels, flow rates, and tank levels.
    • •
      ​​Food and Beverage:​​ Controlling process variables like temperature and fill levels.

Q68AD-G Important Parameters

The key specifications for the Mitsubishi Q68AD-G module are summarized in the table below.
Parameter
Specification
​​Model​​
Q68AD-G
​​Product Type​​
Analog Input Module
​​Number of Channels​​
8 channels
​​Input Signal​​
Voltage / Current (selectable per channel)
​​Rated Input Range (Voltage)​​
-10 to +10 V DC, 0 to 5 V DC, 1 to 5 V DC, etc.
​​Rated Input Range (Current)​​
0 to 20 mA DC, 4 to 20 mA DC
​​Digital Output Resolution​​
16-bit signed binary (Effective resolution: 1/60,000)
​​Conversion Speed​​
80 µs/channel
​​Accuracy (at 25°C)​​
±0.1% (of full scale)
​​Isolation Method​​
Photocoupler isolation between analog and digital circuits. No isolation between channels.
​​Supported PLC Series​​
MELSEC Q Series
​​Required Power Supply​​
5V DC (from the main base unit or extension power module)
​​External Wiring Method​​
40-pin connector (Requires a separate connector block, e.g., A6CON1/2)








性能仕様

入力仕様
アナログ入力点数
アナログ入力 電圧
電流
デジタル出力
入出力特性,分解能 入力レンジ
電圧入力 0～10V
0～5V
1～5V
1～5V(拡張モード)
-10～10V
ユーザレンジ設定
電流入力 0～20mA
4～20mA
4～20mA(拡張モード)
ユーザレンジ設定
精度(デジタル出力値の最大値に対する精度) 基準精度
温度係数
コモンモード特性
サンプリング周期
応答時間
絶対最大入力 電圧
電流
共通仕様
絶縁方式
絶縁耐圧
絶縁抵抗
外部配線接続方式
適合コネクタ
入出力占有点数
DC5V内部消費電流
外形寸法 高さ(H)
幅(W)
奥行き(D)
質量

8点(8チャンネル)
DC-10～+10V(入力抵抗値:1MΩ以上)
DC0～20mA(入力抵抗値:250Ω)
通常分解能モード:-4096～+4095
高分解能モード:-12288～+12287,-16384～+16383
(スケーリング機能使用時:-32768～32767)
デジタル出力値(分解能)
通常分解能モード:0～4000(2.5mV)
高分解能モード:0～16000(0.625mV)
通常分解能モード:0～4000(1.25mV)
高分解能モード:0～12000(0.416mV)
通常分解能モード:0～4000(1.0mV)
高分解能モード:0～12000(0.333mV)
通常分解能モード:-1000～4500(1.0mV)
高分解能モード:-3000～13500(0.333mV)
通常分解能モード:-4000～4000(2.5mV)
高分解能モード:-16000～16000(0.625mV)
通常分解能モード:-4000～4000(0.375mV)
高分解能モード:-12000～12000(0.333mV)
通常分解能モード:0～4000(5µA)
高分解能モード:0～12000(1.66µA)
通常分解能モード:0～4000(4µA)
高分解能モード:0～12000(1.33µA)
通常分解能モード:-1000～4500(4µA)
高分解能モード:-3000～13500(1.33µA)
通常分解能モード:-4000～4000(1.37µA)
高分解能モード:-12000～12000(1.33µA)
±0.1％
±71.4ppm／℃(0.00714％／℃)
同相電圧　入力とコモン接地間(入力電圧0V):AC500V
同相電圧除去比　(VCM＜500V):60Hz 107dB,50Hz 106dB
10ms／チャンネル
20ms
±15V
±30mA

入力端子とシーケンサ電源間,アナログ入力チャンネル間:トランス絶縁
入力端子とシーケンサ電源間:AC500Vrms　1分間
アナログ入力チャンネル間:AC1000Vrms　1分間
入力端子とシーケンサ電源間,アナログ入力チャンネル間:DC500V　10MΩ以上
40ピンコネクタ
A6CON1,A6CON2,A6CON4(別売)
16点(I/O割付:インテリ 16点)
0.46A
102mm
27.4mm
90mm
0.16kg
