QD65PD2 Mitsubishi Universal Model Redundant Power Supply Module 5 V DC/3 A

QD65PD2 Description

QD65PD2 Key Features

• Ultra-High-Speed Counting: Supports up to 8 Mpps (differential input, 2-phase 4x multiplication) and 200 kpps (DC input), ideal for high-resolution encoder feedback.
• Multi-Function Integration: Combines high-speed counter, pulse measurement (100 ns resolution), PWM output (up to 200 kHz), and cam switch control in one module.
• Versatile Input Compatibility: Accepts EIA RS-422-A differential line driver signals and DC 5/12/24 V inputs, supporting 1-phase, 2-phase, and CW/CCW pulse formats.
• High-Precision PWM Control: Features 0.1 µs resolution for PWM duty cycle adjustment, enabling ultra-fine output control.
• Advanced Cam Switch Function: Configurable for up to 16 steps/point with 8 dedicated transistor (sink-type) outputs for precise, event-based timing control.
• Flexible Counting Modes: Supports linear and ring counter formats, with preset, replace, and latch counter functions.
• Wide Counting Range: 32-bit signed binary counting range (-2147483648 to 2147483647).
• Robust Isolation & Protection: Optical isolation between input/output and internal PLC circuits for high noise immunity.
• Compact Design: Slim 1-slot width (27.4 mm) for high-density mounting in Q Series racks.
• Diagnostic LEDs: Equipped with status indicators for power, counting, and error monitoring.
• Global Certifications: Conforms to UL, cUL, CE (EMC/RoHS), KC, and marine standards (LR, DNV, ABS, RINA, BV).

QD65PD2 Materials & Applications

Materials

• Housing & Enclosure: High-strength, flame-retardant (UL94 V-0) engineering thermoplastic, ensuring durability and electrical safety.
• Circuit Board: Multi-layer FR-4 glass epoxy PCB with heavy copper traces for signal integrity and efficient heat dissipation.
• Connectors: Two 40-pin industrial-grade connectors (compatible with A6CON1, A6CON2, A6CON4) for secure, high-density wiring.
• Internal Components: Industrial-grade high-speed optocouplers, precision resistors, and capacitors designed for long-term stability under high-frequency operation.
• Terminals: Nickel-plated copper alloy contacts for secure, corrosion-resistant connections.

Typical Applications

• Semiconductor & LCD Manufacturing: High-precision positioning and speed control for wafer scribers, die bonders, and panel processing machinery.
• High-Speed Packaging & Printing: Precise registration control, web tension control, and cut-to-length operations.
• Machine Tools: High-resolution position feedback for CNC axes, spindle speed monitoring, and tool positioning.
• Robotics & Automation: Precise joint angle measurement and motion control for industrial robots and linear actuators.
• Test & Measurement: High-speed event counting, pulse width analysis, and frequency measurement for automated test equipment.
• Material Handling: High-speed conveyor tracking, part sorting, and accurate length/position measurement.
• Textile & Fiber Processing: Precise length counting, tension control, and high-speed synchronization.

QD65PD2 Important Parameters
