Q80BD-J71GP21S-SX Mitsubishi Universal Model Redundant Power Supply Module

Mitsubishi Universal model Redundant Power Supply Module Q80BD-J71GP21S-SX

• Gigabit High-Speed Communication:​ Leverages CC-Link IE Field Network protocol for gigabit (1Gbps) data transmission, enabling high-speed, high-capacity cyclic and transient data exchange for real-time control and monitoring.
• Large-Scale Network Connectivity:​ Supports connection of up to 120 stations (maximum) per network, allowing for the construction of extensive and complex control systems.
• Enhanced Synchronization:​ Supports synchronous communication functions, ensuring precise timing control across connected devices, which is critical for motion control and synchronized production lines.
• Built-in Switching Hub:​ Features 4 built-in RJ45 ports with an integrated switching hub function, enabling flexible star, line, or combination network topologies without the need for external switches, simplifying network design and cabling.
• RAS Functions (Reliability, Availability, Serviceability):​ Includes network diagnostics, loopback function, and cable disconnection detection to enhance network reliability and simplify maintenance and troubleshooting.
• Seamless Integration with Q PLC:​ Directly mounted on the Q Series main base, it allows for high-speed data sharing between the CPU and network using dedicated instructions and buffer memory, optimizing system performance.
• Web Browser Diagnostics:​ Supports web server function, allowing network status monitoring and basic diagnostics via a standard web browser for easier maintenance.

• Materials:​ High-quality PCB with industrial-grade components, metal bracket for secure mounting and EMI shielding, and robust RJ45 connectors with industrial-grade durability.
• Primary Applications:​
  • Large-scale factory automation and production line control
  • High-speed, synchronized motion control systems
  • Integrated control in automotive manufacturing and assembly plants
  • Semiconductor and electronic component production lines
  • High-speed material handling and logistics control systems
  • Process control systems requiring extensive device networking
