QY23L Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC

QY23L Mitsubishi Universal model Redundant Power Supply Module

QY23L Description

QY23L Features

• •
  ​​Relay Contact Outputs:​​ The primary feature is the use of relay contacts, which allow it to switch a wide range of voltages (AC or DC) and provide complete electrical isolation, protecting the PLC from voltage surges and electrical noise from the load side.
• •
  ​​16 Independent Points:​​ Features 16 independent output channels (points), organized in a common configuration. This means the points are grouped with a common terminal for efficient wiring.
• •
  ​​Robust and Reliable:​​ Designed for high reliability in harsh industrial environments, with a long mechanical life for the internal relays.
• •
  ​​Easy Installation:​​ Mounts directly on the MELSEC-Q series base unit (e.g., a Q35B or Q38B). The terminals use a removable clamp-style terminal block, making wiring and maintenance quick and easy.
• •
  ​​Diagnostic LEDs:​​ Each output point has an LED indicator that lights up when the output is active, providing clear visual status for troubleshooting. A module power (PWR) LED indicates the health of the module.
• •
  ​​High Load Capacity:​​ Relay outputs can handle higher inrush currents (like those from inductive loads such as solenoids and contactors) better than transistor outputs.

QY23L Material and Application

• •
  ​​Primary Material:​​ The module housing is made from high-grade, flame-retardant plastic. The internal circuitry uses standard electronic components, and the output terminals are typically plated metal (e.g., tin or nickel) for good conductivity and corrosion resistance.
• •
  ​​Usage/Application:​​ This module is used to control a wide variety of industrial AC/DC devices that require switching. Common applications include:
  • •
    Controlling solenoid valves for pneumatic or hydraulic systems.
  • •
    Energizing motor contactors and starters.
  • •
    Operating indicator lights, alarms, and horns.
  • •
    Automating packaging machinery, conveyor systems, and assembly lines.

QY23L Key Parameters

性能仕様
