AJ65SBTB1-32D5 Mitsubishi Universal Model Redundant Power Supply Module

AJ65SBTB1-32D5 Description

AJ65SBTB1-32D5 Key Features

• 32-Point High-Density Input: Maximizes I/O capacity in minimal panel space
• Flexible Sink/Source Compatibility: Supports both positive and negative common input wiring
• Configurable Response Time: 3-speed selectable (2ms / 10ms / 50ms) via DIP switch for high-speed detection or contact bounce suppression
• Wide Input Voltage Range: DC 16.8V–26.4V, compatible with most 24V DC industrial sensors
• Photocoupler Isolation: 2,500V AC electrical isolation between input channels and internal logic for superior noise immunity
• Individual LED Indicators: Per-point status LEDs for quick diagnostics and monitoring
• Screw Terminal Block: Secure, removable screw terminals for easy wiring and maintenance
• CC-Link Ver. 1.10 Compatible: Occupies 1 remote device station
• DIN-Rail Mountable: Standard industrial installation for quick assembly
• Comprehensive Certifications: UL, cUL, CE, and RoHS compliant

AJ65SBTB1-32D5 Materials & Applications

Materials

• Housing: Flame-retardant, high-impact thermoplastic resin (UL94 V-0 rated)
• Terminals: Nickel-plated copper screw terminals for corrosion resistance and stable connection
• Circuit Board: High-temperature FR-4 PCB with conformal coating
• Internal Components: High-speed optocouplers, precision resistors, and multi-color LED indicators
• Connector: 40-pin industrial-grade internal connector for CC-Link interface

Typical Applications

• Factory Automation: Connecting limit switches, proximity sensors, photoelectric sensors, and pushbuttons
• Packaging Machinery: High-speed input detection for conveyor positioning and counting
• Assembly Lines: Monitoring part presence, machine status, and operator controls
• Material Handling: Input signals from automated warehouses, sorting machines, and robotic cells
• Machine Tools: Interlock signals, emergency stops, and tool position sensors
• General Industrial Equipment: Distributed digital signal monitoring in control cabinets
• Automotive Manufacturing: Body shop, welding, and painting line sensor inputs

AJ65SBTB1-32D5 Important Parameters
