AJ65SBTB2-16T1 Mitsubishi Universal Model Redundant Power Supply Module 0.12 μS

AJ65SBTB2-16T1 Description

AJ65SBTB2-16T1 Key Features

• 16 Independent Output Channels: 16-channel transistor output for high-density on-site load control.
• PNP Source-Type Output: Adopts PNP transistor output type, compatible with common industrial DC load systems.
• High-Speed Response Performance: Fast switching response ensures synchronization requirements of high-speed automation sequences.
• Optocoupler Galvanic Isolation: Complete electrical isolation between field output circuit and internal bus circuit to suppress electromagnetic interference.
• CC-Link Fieldbus Compatible: Standard fieldbus communication, occupies only one station address to save network resources.
• Front Panel LED Indicators: Dedicated LEDs for power, network communication and each channel status for rapid inspection and troubleshooting.
• Screw Terminal Connection: Firm screw terminal wiring, anti-loose and suitable for strong vibration working conditions.
• DIN-Rail Mounting: Standard DIN rail installation, easy cabinet layout, assembly and system expansion.
• Built-in Surge Suppression: Internal absorption circuit protects transistor components and rear-end loads from voltage surge damage.
• Low Power Consumption: Energy-saving circuit design reduces overall system power load.
• Wide Environmental Adaptation: Withstands temperature fluctuation, humidity and mechanical shock in factory environments.

AJ65SBTB2-16T1 Materials & Applications

Materials

• Housing: High-strength flame-retardant engineering plastic with UL94 V-0 rating, excellent insulation, impact resistance and aging resistance.
• Circuit Board: High-quality FR-4 glass epoxy multilayer PCB with industrial SMT process, stable heat dissipation and signal transmission.
• Terminals: Nickel-plated brass screw terminals with corrosion resistance and reliable long-term wiring contact.
• Internal Components: Industrial-grade switching transistors, high-reliability optocouplers, voltage regulation and surge protection components.
• Indicator Lights: Long-life high-brightness LED indicators for clear power, network and channel status display.

Typical Applications

• Factory Automation: Control of pneumatic solenoid valves, hydraulic valves, intermediate relays and signal lamps.
• Assembly Lines: Clamping mechanism, positioning actuator and process sequence control.
• Packaging Machinery: Labeling, sealing, filling and wrapping equipment actuator control.
• Material Handling: Conveyor system start-stop, sorting mechanism and diverter drive control.
• Machine Tools: Coolant system, lubrication system and safety interlock loop control.
• Food & Beverage Automation: Production line conveying, dosing valve and packaging actuator control.
• Textile & Printing Machinery: Transmission mechanism, tension control and roller drive signal output.
• General Industrial Control: Distributed on-site I/O expansion for various automated production equipment.

AJ65SBTB2-16T1 Important Parameters
