MSME402GCGM+MFDKTB3A2CA1 MINAS A5II 4KW servo motor&drive& 20-bit 200V
The Panasonic MSME402GCGM is a 4KW (4000W) small inertia AC servo motor, designed to be paired with the MFDKTB3A2CA1 servo drive (also referred to as an amplifier or driver). This system is part of Panasonic's extensive servo product lineup, renowned for high precision and reliability in industrial automation. The combination utilizes a pulse train command interface for precise positional control, where the motor rotates a specific angle for each pulse received, enabling extremely accurate displacement control down to microns. This makes the system ideal for demanding applications requiring high-speed response and exceptional positioning accuracy
High Precision Control: Offers exceptionally precise positioning, capable of achieving accuracies as fine as 0.001mm, which is critical for advanced automated equipment
.
Pulse-Based Operation: Functions on a pulse command system, ensuring smooth and accurate motion control. The system forms a closed loop, as the motor sends back feedback pulses to the drive, confirming its position
.
Compact and Efficient Design: Through optimized thermal analysis and design innovations, Panasonic has managed to reduce the size and weight of their servo components compared to previous generations, contributing to a more compact machine footprint
.
High Reliability: Designed for robust performance in challenging industrial environments, ensuring consistent operation and reduced downtime
.
Flexible Configuration: The drive supports various control modes (e.g., torque, speed, position) and is designed to work seamlessly with its matched motor型号, simplifying integration and setup
.
The motor is constructed with high-quality materials, including electromagnetic steel laminations to minimize iron losses and ensure efficient operation
. The specific material composition of the housing and internal components is engineered for durability, heat dissipation, and longevity.
Primary Applications:
This 4KW servo system is built for high-performance industrial automation tasks, including:
Industrial Machinery: CNC machining centers, precision lathes, grinding machines
.
Semiconductor Manufacturing: Equipment like die bonders, wire bonders, and chip mounters
.
Robotics: High-speed multi-axis robots, robotic arms (e.g., pick-and-place units)
.
Packaging and Printing: High-speed packaging machines and precision printing equipment
.
Automation Equipment: Various specialized industrial machines requiring precise motion control.
The key technical specifications for the MSME402GCGM motor and MFDKTB3A2CA1 drive combination are summarized in the table below.
|
Parameter Category |
Specification Detail |
Notes / Source |
|---|---|---|
| Motor Model | MSME402GCGM |
Panasonic 4KW Small Inertia Servo Motor
|
| Drive/Amplifier Model | MFDKTB3A2CA1 |
Matched servo drive for the motor
|
| Output Power | 4 kW (4000 W) |
Rated power output
|
| Inertia Type | Small Inertia |
Optimized for high responsiveness and rapid acceleration/deceleration
|
| Control Interface | Pulse Train Input |
Standard pulse command for position control
|
| Brake Option | Available (GCH suffix) |
Some motor variants include an integral brake
|
| Typical Applications | CNC, Robotics, Semicon | Industrial au |
