MHMD082G1U AC Motor Servomotor 3000 RPM 750W Incremental 200VAC Panasonic
MHMD082G1U Description
The Panasonic MHMD082G1U is a high-performance AC servo motor belonging to the manufacturer's MINAS A5 series family
. It is designed for industrial automation applications requiring precise motion control, high torque, and reliable operation. This 750W servo motor operates at a rated speed of 3000 RPM and is equipped with a 20-bit incremental encoder for exceptional positional accuracy
. It is commonly used in conjunction with compatible Panasonic servo drives for a complete motion control solution
.
MHMD082G1U Features
- •
High Performance: Delivers 750W of power with a rated torque of 2.4 N·m (2400 mNm) and a high maximum momentary torque for demanding applications
.
- •
Precision Encoding: Features a 20-bit incremental encoder, providing high-resolution feedback for precise positioning and smooth operation
.
- •
Robust Design: The motor is built with a durable construction. Some variants in the series offer protection levels up to IP67, making them resistant to dust and moisture for use in harsh industrial environments
.
- •
Compact Form Factor: Designed with an 80mm frame size (Square - 80.00mm x 80.00mm), offering a high power-to-size ratio
.
- •
Comprehensive Safety Approvals: Complies with international standards and carries approvals from agencies such as CE, CSA, cULus, TUV, and UL
.
- •
Integrated Options: Some models may include features like a brake or key for enhanced functionality and safety
.
Materials & Primary Uses
- •
Materials: The motor incorporates a steel shaft, high-grade magnets, copper windings, and durable housing materials designed for industrial endurance.
- •
Primary Uses: This servo motor is ideal for a wide range of automation applications, including:
- •
CNC machinery
- •
Packaging and printing equipment
- •
Robotic arms and automation systems
- •
Textile machinery
- •
LCD manufacturing equipment
- •
Other precision industrial applications requiring reliable and accurate motion control
MHMD082G1U Important Parameters
The key specifications for the Panasonic MHMD082G1U servo motor are summarized in the table below.
|
Parameter Category
|
Specification
|
Value / Rating
|
| Model & Series |
Model Number |
MHMD082G1U |
| |
Series |
MINAS A5 Family |
| Power Ratings |
Rated Power |
750 W |
| |
Rated Voltage |
200 VAC |
| |
Rated Current |
4.8 A |
| Performance |
Rated Speed |
3000 RPM |
| |
Rated Torque |
2.4 N·m (2400 mNm) |
| |
Max. Momentary Torque |
7.1 N·m (7100 mNm) |
| Physical |
Frame Size |
Square, 80mm x 80mm |
| |
Shaft Diameter |
19 mm |
| |
Weight |
3.1 kg (approx.) |
| |
Mounting Hole Spacing |
90.00 mm |
| Encoder & Feedback |
Encoder Type |
20-bit Incremental |
| Environmental |
Operating Temperature |
0°C to +40°C |
| |
Protection Level (IP) |
IP67 (Depending on variant) |
| Compliance |
Approvals |
CE, CSA, cULus, TUV, UL |
| |
RoHS Status |
Compliant |
