AJ65BTB1-16DT Mitsubishi Universal Model Redundant Power Supply Module 24VDC

AJ65BTB1-16DT Description

AJ65BTB1-16DT Key Features

• Mixed I/O Configuration: 8×DC24V positive common digital inputs + 8×DC24V sink-type transistor outputs (16 total I/O points)
• Screw Terminal Block: Secure M3 screw terminals for stable wiring (0.5–1.5mm² cable), suitable for industrial field wiring
• Optocoupler Isolation: Full photoelectric isolation between input/output/internal circuits, strong anti-interference
• Fast Response: Input response ≤10ms; Output response ≤1.5ms, ensuring real-time control
• High Load Capacity: 0.5A per output point, 2.4A per common terminal, reliable for small actuators
• Low Leakage Current: ≤0.1mA OFF-state leakage, preventing misoperation
• Split Terminal Design: Two-piece terminal block allows module replacement without rewiring
• Wide Voltage Range: Input/output: DC19.2–28.8V; Module power: DC20.4–26.4V
• DIN Rail & Screw Mount: Flexible installation (DIN rail or direct panel mounting)
• Global Certifications: UL, cUL, CE (EMC/RoHS), KC compliant
• Compact & Lightweight: Slim profile for space-saving cabinet layout

AJ65BTB1-16DT Materials & Applications

Materials

• Housing: Flame-retardant engineering plastic (UL94 V-0), high impact & heat resistance
• Terminals: Nickel-plated copper screw terminals, corrosion-resistant, low contact resistance
• Internal PCB: High-temperature FR-4 glass epoxy board with industrial-grade components
• Isolation: High-performance optocouplers for signal & power isolation
• Internal Parts: Stable electrolytic capacitors, resistors, and driver ICs for harsh environments

Typical Applications

• Factory Automation: Connects sensors (proximity/photoelectric/limit switches) and actuators (solenoids/relays/small valves)
• CC-Link Networks: Distributed I/O for assembly lines, packaging machines, material handling
• Machine Tools: I/O control for CNC machines, presses, automated workstations
• Conveying Systems: Position detection and conveyor drive control
• Packaging & Printing: Sensor input and actuator control for labeling/filling equipment
• Food & Beverage: Hygienic automation with distributed I/O monitoring
• Material Handling: AS/RS, warehouse automation, small equipment control
• General Industrial: Automotive, textile, semiconductor equipment I/O interfaces

AJ65BTB1-16DT Important Parameters
