AJ65BT-D62 Mitsubishi Universal Model Redundant Power Supply Module

AJ65BT-D62 Mitsubishi Universal model Redundant Power Supply Module

AJ65BT-D62  Key Features

• •
  ​​High-Speed Counting​​: Supports counting speeds up to ​​200k pulses per second​​ for 1-phase inputs and ​​200k pulses per second​​ for 2-phase inputs, ensuring accurate tracking of high-speed events .
• •
  ​​Dual-Channel Operation​​: Features ​​2 independent channels​​ that can be configured for various counting modes, including 1-phase and 2-phase inputs, providing flexibility for different application requirements .
• •
  ​​Wide Input Compatibility​​: Accepts count input signals at ​​DC 5V, 12V, and 24V​​ levels, allowing integration with a broad range of industrial sensors and encoders .
• •
  ​​CC-Link Network Integration​​: Functions as a remote device station on the CC-Link network, enabling distributed control and real-time data exchange with the master PLC.
• •
  ​​Advanced Counting Modes​​: Offers multiple counting modes, including ​​UP/DOWN preset counting​​ and ​​ring counter functionality​​, with a 24-bit signed binary counting range (0 to 16,777,215) for precise control .
• •
  ​​Coincidence Output Function​​: Includes transistor outputs (open collector) for coincidence detection, with a fast response time of ​​0.1 ms or less​​, facilitating quick reaction to count matches .
• •
  ​​Compact and Robust Design​​: Designed with a ​​terminal block connection type​​ for secure wiring in industrial environments, occupying ​​4 stations​​ on the CC-Link network .

AJ65BT-D62  Material & Primary Applications

• •
  ​​Material​​: The module is housed in a robust industrial-grade casing designed to withstand harsh environments. It features terminal blocks with M3.5 screws for secure connections and is built to resist industrial noise and interference .
• •
  ​​Primary Applications​​:
  • •
    ​​Motion Control Systems​​: Ideal for precise position and speed control in automated machinery and robotics.
  • •
    ​​Production Line Monitoring​​: Used for counting products, monitoring conveyor belt speeds, and controlling sequential operations.
  • •
    ​​Test and Measurement Equipment​​: Suitable for applications requiring accurate pulse counting and frequency measurement.
  • •
    ​​Packaging and Material Handling​​: Provides high-speed counting for filling, capping, and sorting operations.

AJ65BT-D62  Key Parameters Table
