AJ65DBTB1-32R Mitsubishi Universal Model Redundant Power Supply Module 0.12 μS

Name: AJ65DBTB1-32R Mitsubishi Universal Model Redundant Power Supply Module 0.12 μS
Brand: Shenzhen Wisdomlong Technology CO.,LTD
SKU: AJ65DBTB1-32R
Price: 10000 USD
Availability: InStock

Product Details:

Place of Origin:	Japan
Brand Name:	MITSUBISHI
Certification:	CE
Model Number:	AJ65DBTB1-32R

Detail Information

Place of Origin:

Japan

Brand Name:

MITSUBISHI

Certification:

Model Number:

AJ65DBTB1-32R

Brand:

MITSUBISHI

Modenl Number:

AJ65DBTB1-32R

Country Of Origin:

Japan

Program Capacity:

8 K Steps

Basic Operation Processing Speed (LD Instruction):

0.12 μs

Input:

100 To 240 V AC

Output:

5 V DC/3 A

Type:

Redundant Power Supply Module

Highlight:

High Light

Highlight:

plc power supply module

diode redundancy module

Trading Information

Minimum Order Quantity:

Price:

Contact

Packaging Details:

NEW AND ORIGINAL

Delivery Time:

3-5DAYS

Payment Terms:

T/T, Western Union,paypal

Supply Ability:

100

Product Description

AJ65DBTB1-32R Mitsubishi Universal model Redundant Power Supply Module

AJ65DBTB1-32R Description

The Mitsubishi AJ65DBTB1-32R is a high-density, compact CC-Link remote I/O module from the MELSEC-A series, designed exclusively for 32-point relay output control in industrial automation systems. Acting as a remote output station on the CC-Link field network, it receives control signals from the main PLC and switches various field loads via its built-in electromechanical relays. This module provides a robust, cost-effective solution for distributed control applications requiring a large number of isolated, multi-voltage load switching points.

AJ65DBTB1-32R Key Features

High-Density Relay Output: 32 independent relay output points for maximum wiring efficiency
CC-Link Network Compatibility: Fully compliant with CC-Link Ver. 1.1, occupying 1 station
Multi-Voltage Load Support: Relay contacts switch both DC 24V and AC 240V loads
High Current Capacity: 2A per point and 4A per common terminal (max. 16A total)
Isolated Outputs: Full optoelectronic isolation between internal logic and field outputs
Long-Life Relays: Mechanical life ≥ 10 million operations; Electrical life ≥ 100,000 operations
Space-Saving Design: Slim, compact housing for efficient DIN-rail mounting
Secure Screw Terminals: 50-point M3.5 screw terminal block for reliable, vibration-resistant connections
Grouped Commoning: 4-point common configuration (8 groups total) for flexible wiring
Clear Status LEDs: Individual LED indicators for each output and network status
Industrial Durability: High resistance to vibration, shock, and temperature fluctuations
Global Standards: UL, cUL, and CE certified for international use

AJ65DBTB1-32R Materials & Applications

Materials

Housing: High-strength, flame-retardant thermoplastic (UL 94 V-0 rated)
Terminal Block: Nickel-plated copper alloy for excellent conductivity and corrosion resistance
Internal PCB: FR-4 glass epoxy with durable conformal coating
Output Relays: High-quality electromechanical relays with silver-alloy contacts
Mounting Base: Reinforced plastic for secure 35mm DIN-rail installation

Typical Applications

Factory Automation: Control of solenoid valves, contactors, and relays on production lines
Material Handling: Conveyor systems, packaging machines, and sorting equipment
Process Control: Actuation of pneumatic/hydraulic valves and pump motors
Building Automation: Lighting control, HVAC systems, and access control
Machine Tools: Spindle control, coolant systems, and safety interlocks
Power Distribution: Circuit breaker control and power management
Food & Beverage: Filling, sealing, and labeling machinery
Automotive Manufacturing: Welding lines, paint booths, and assembly stations

AJ65DBTB1-32R Important Parameters

Parameter	Specification
Part Number	AJ65DBTB1-32R
Brand	Mitsubishi Electric (MELSEC)
Series	CC-Link Compact Remote I/O
Network Type	CC-Link (Ver. 1.1)
Station Type	Remote Output Station
Occupied Stations	1 station
Output Specifications
Output Type	Relay Contact (Normally Open - NO)
Number of Outputs	32 points
Rated Load Voltage	DC 24V / AC 240V
Rated Load Current	2A per point (resistive load)
Common Current	4A per common
Total Load Current	Max. 16A per module
Output Common	4 points / common (8 groups)
Contact Material	Silver alloy
Mechanical Life	≥ 10,000,000 operations
Electrical Life	≥ 100,000 operations (at rated load)
Output Response Time	≤ 12 ms
Isolation	Optocoupler isolation
General Specifications
Power Supply	DC 24V ±10%
Internal Current Consumption	Approx. 80mA (0.08A)
Insulation Voltage	1500V AC (between internal circuits and external I/O)
Dimensions (W × H × D)	64 × 170 × 70 mm
Weight	Approx. 0.7 kg
Mounting	35mm DIN rail
Operating Temperature	0 ~ +55 °C
Storage Temperature	-20 ~ +75 °C
Operating Humidity	10 ~ 90% RH (non-condensing)
Vibration Resistance	5 ~ 150Hz, 9.8m/s² (conforms to JIS B 3502, IEC 61131-2)
Shock Resistance	147 m/s² (15G)
Protection Rating	IP1X (finger-safe terminal block)
Standards	IEC 61131-2, UL 508, cUL, CE
Country of Origin	Japan
