AJ65MBTL1N-16D Redundant Power Supply Module Mitsubishi Universal Model 0.12 μS

Redundant Power Supply Module Mitsubishi Universal model AJ65MBTL1N-16D

AJ65MBTL1N-16D Description

AJ65MBTL1N-16D Key Features

• 16-Channel Digital Input: Provides 16 independent DC input points for collecting a large number of field switching signals simultaneously.
• Positive Common Configuration: Designed with a positive common terminal (sink input type), compatible with most 24V DC industrial sensors and switches.
• High-Speed Signal Response: Fast input response time ensures real-time transmission of switching status for precise control.
• Optocoupler Galvanic Isolation: Complete electrical isolation between input circuits and internal bus logic, effectively suppressing electromagnetic interference (EMI) in industrial environments.
• Fieldbus Communication: Seamless integration with standard industrial fieldbus protocols, occupying only one station address to optimize network resources.
• Compact & Lightweight: Ultra-slim, lightweight form factor for installation in space-constrained control cabinets and equipment.
• Connector Wiring: Uses a standard 44-pin connector for fast, reliable wiring and easy installation/replacement.
• LED Status Indicators: Equipped with LEDs for power, communication status, and input signal status, enabling quick diagnostics and maintenance.
• Industrial-Grade Durability: Resistant to vibration, shock, and wide temperature variations for stable operation in harsh factory conditions.
• Low Power Consumption: Energy-efficient design minimizes the power load on the system's power supply.

AJ65MBTL1N-16D Materials & Applications

Materials

• Housing: High-strength, flame-retardant engineering plastic (UL94 V-0 rated), offering excellent insulation and impact resistance.
• Circuit Board: High-quality FR-4 glass epoxy multilayer PCB, ensuring stable signal transmission and heat dissipation.
• Internal Components: Industrial-grade optocouplers, current-limiting resistors, filter capacitors, and voltage regulation chips for reliable signal conditioning.
• Connectors: Durable 44-pin industrial connector with gold-plated contacts for corrosion resistance and stable electrical connection.
• Indicators: Long-life, high-brightness LED lamps for clear visibility of operational status.

Typical Applications

• Factory Automation: Signal collection from limit switches, proximity sensors, photoelectric sensors, and emergency stop buttons.
• Machine Tools: Position detection, stroke control, and safety interlock signal input for machining centers.
• Assembly & Packaging Lines: Part presence detection, positioning signals, and operation mode selection.
• Material Handling Systems: Conveyor speed control, sorting detection, and transfer position feedback.
• Food & Beverage Machinery: Bottle counting, level detection, and safety door status monitoring.
• Textile & Printing Equipment: Yarn break detection, registration mark sensors, and operation panel inputs.
• HVAC & Building Automation: Filter status, valve position, and thermostat signal acquisition.
• General Industrial Control: Distributed I/O expansion for various automated machines and test equipment.

AJ65MBTL1N-16D Important Parameters
