AJ35PTF-28AS Redundant Power Supply Module Mitsubishi Universal model
AJ35PTF-28AS Overview:
The Mitsubishi AJ35PTF-28AS is a high-density transistor output module designed for Mitsubishi's MELSEC-A series programmable controllers. This 28-point transistor output module delivers reliable digital output control for industrial automation applications, featuring fast response times and robust construction to meet demanding manufacturing environment requirements.
AJ35PTF-28AS Key Features:
✔ High-Density Output - 28 points of transistor outputs in a compact form factor
✔ Fast Response Time - Ultra-fast switching for precise process control
✔ Reliable Transistor Outputs - Solid-state design for long service life
✔ Noise Immunity - Superior protection against electrical noise
✔ Seamless Integration - Perfect compatibility with Mitsubishi MELSEC-A series PLCs
✔ Space-Saving Design - Efficient use of control panel space
AJ35PTF-28AS Technical Specifications:
| Parameter |
Specification |
| Module Type |
Transistor Output Module |
| Part Number |
AJ35PTF-28AS |
| Output Points |
28 points (14 points per common) |
| Output Type |
NPN open collector transistors |
| Rated Voltage |
24V DC ±10% |
| Maximum Current per Point |
0.5A |
| Total Current per Common |
4A (max) |
| Response Time |
0.2ms or less (ON/OFF) |
| Insulation Method |
Photo-coupler isolation |
| Protection Functions |
Overcurrent protection |
| Operating Temperature |
-10°C to +55°C |
| Weight |
Approximately 0.2kg |
(Note: Exact specifications may vary - consult Mitsubishi's official documentation for precise details.)
AJ35PTF-28AS Product Details:
Functionality:
The AJ35PTF-28AS module provides:
- Digital output control for industrial devices
- Fast switching for time-critical applications
- Reliable operation in electrically noisy environments
- Easy integration with Mitsubishi MELSEC-A series PLCs
Design & Construction:
- Compact and lightweight for easy panel mounting
- High-quality components for long-term reliability
- Photo-coupler isolation for enhanced noise immunity
- Durable terminals for secure connections
Applications:
- Factory automation systems
- Material handling equipment
- Packaging machinery
- Semiconductor manufacturing
- Textile and printing equipment
- Machine tools and robotics
Why Choose Mitsubishi AJ35PTF-28AS?
✅ Proven Reliability - Mitsubishi's industry-leading PLC components
✅ High Performance - Fast response times for precise control
✅ Easy Integration - Seamless compatibility with MELSEC-A series
✅ Space Efficiency - High-density output in compact form factor
✅ Robust Construction - Designed for industrial environments
Ordering Information:
- Part Number: AJ35PTF-28AS
- Standard Accessories:
- Installation manual
- Terminal block (if required)
- Wiring diagram
- Packaging: Individual anti-static packaging
- Availability: Standard lead time: 2-4 weeks
AJ35PTF-28AS Recommended System Components:
| Component |
Recommendation |
| PLC CPU |
Mitsubishi MELSEC-A series CPU (e.g., A0J2H, A1SH) |
| Power Supply |
Mitsubishi MELSEC-A series power supply unit |
| Input Modules |
AJ35PTF-28AS companion input modules if needed |
| Programming Software |
GX Developer or GX Works2 |
AJ35PTF-28AS Technical Documentation:
- Datasheet - Complete electrical and mechanical specifications
- Installation Manual - Detailed installation instructions
- Configuration Guide - Wiring and connection guidelines
- Application Notes - Example applications and programming tips
Additional Notes:
- Exact wiring diagrams should be consulted before installation
- Current capacity should not be exceeded to prevent damage
- Noise protection measures should be implemented in electrically noisy environments
