AJ35PTF-56DS Redundant Power Supply Module Mitsubishi Universal Model

AJ35PTF-56DS Description

AJ35PTF-56DS Key Features

• High-Density I/O Integration: 32 DC input points + 24 AC triac output points (56 total), compact design to save panel space.
• CC-Link Compatibility: Seamless communication with Mitsubishi A/Q-series PLCs via CC-Link fieldbus, supports remote I/O expansion up to 8 stations.
• Fast Response & Stable Switching: DC input response time ≤10ms; triac output response time ≤1ms (0.5Hz +1ms), suitable for high-speed industrial control loops.
• Flexible Input Configuration: Positive common (sourcing) DC input, compatible with 12/24V DC sensors, switches, and proximity detectors.
• Robust Triac Output: 24 bidirectional triac outputs for AC 100–240V loads, 0.6A per point / 2.4A per common terminal, no contact wear, long electrical life.
• Easy Wiring & Installation: Dual 36-pin screw terminal blocks, grouped common terminals (16 inputs/common, 8/4 outputs/common), DIN-rail mountable.
• Comprehensive Protection: Built-in overcurrent, surge, and reverse polarity protection for input/output circuits; LED status indicators for power, communication, and I/O status.
• Wide Environmental Rating: Operates from -10°C to +55°C, 5–95% RH (non-condensing), suitable for industrial automation environments.
• Global Certifications: CE, UL, and RoHS compliant for worldwide industrial deployment.

AJ35PTF-56DS Materials & Applications

Materials

• Housing & Frame: High-strength, flame-retardant UL94 V-0 thermoplastic, impact-resistant, heat-stable, and dust-proof.
• Terminal Blocks: Tin-plated copper screw terminals, anti-oxidation, secure connection for high-current AC/DC signals.
• Internal Circuitry: Industrial-grade FR-4 PCB with conformal coating, resistant to vibration, humidity, and industrial contaminants.
• Triac Output Components: High-performance bidirectional thyristors (triacs) with thermal dissipation design, ensuring stable AC switching.
• Input Circuitry: Opto-isolators for electrical isolation between field signals and PLC bus, enhancing noise immunity.

Typical Applications

• Factory Automation: Assembly lines, packaging machines, sorting systems, and material handling equipment.
• Machine Tools & CNC: Control of solenoid valves, contactors, indicators, and limit switches in machining centers.
• HVAC & Pump Systems: AC fan, pump, and valve control in industrial ventilation and water treatment systems.
• Conveyor & Logistics: Conveyor motor control, position detection, and interlock signaling in warehouse automation.
• Packaging & Printing: AC load switching for labeling, sealing, and web tension control equipment.
• General Industrial Control: Switching of AC lighting, heaters, small motors, and alarm circuits in manufacturing facilities.

AJ35PTF-56DS Important Parameters
