Product Details:
Payment & Shipping Terms:
|
| Brand: | GE | Model: | IC200ALG264 |
|---|---|---|---|
| Origin: | USA | Type: | PLC Module |
| Highlight: | ewing machine servo motor,electric servo motor |
||
15 Bit Current, 15 Channel IC200ALG264 GE VersaMax Analog Input Module
| IC200ALG262 | IC200ALG263 | IC200ALG264 | |
| Product Name | VersaMax Analog Input Module, 15 Bit Differential Current, 8 Channel |
VersaMax Analog Input Module, 15 Bit Voltage, 15 Channel |
VersaMax Analog Input Module, 15 Bit Current, 15 Channel |
| Lifecycle Status | Active | Active | Active |
| Input Range | 0 to 20 mA or 4 to 20 mA | ±10 VDC | 0 to 20 mA or 4 to 20 mA |
| Number of Channels | 8 | 15 | 15 |
| External Power Supply | None | None | None |
| Resolution | 4 to 20 mA: 0 .5micro Amp= 1 count; 0 to 20 mA: 0 .625micro Amp = 1 count |
Bipolar mode: 0 .3125 mV = 1 count | 4 to 20 mA: 0 .5micro Amp= 1 count; 0 to 20 mA: 0 .625micro Amp = 1 count |
| Update Rate | 7 .5 ms | 7 .5 ms | 7 .5 ms |
| Accuracy at 25°C | ±0 .3% typical of full scale, ±0 .5% maximum of full scale |
±0 .3% typical of full scale, ±0 .5% maximum of full scale |
±0 .3% typical of full scale, ±0 .5% maximum of full scale |
| Input Impedance | Current mode: 100 kOhms maximum |
Voltage mode: 100 kOhms maximum |
Voltage mode: 100 kOhms maximum, Current mode: 200 Ohms maximum |
| Input Filter Response | N/A | N/A | 24 Hz ±20% |
| 5V Backplane Current Consumption (mA) |
200 maximum | 150 maximum | 100 maximum |
| 3 .3V Backplane Current Consumption (mA) |
N/A | N/A | N/A |
| LED Indicators | INT PWR LED indicates internally-generated field power is present . OK LED indicates backplane power is present . |
INT PWR LED indicates internally-generated field power is present . OK LED indicates backplane power is present . |
INT PWR LED indicates internally-generated field power is present . OK LED indicates backplane power is present . |
| Dimensions (W x H x D) | 110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in) , not including the height of the carrier or the mating connectors |
110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in) , not including the height of the carrier or the mating connectors |
110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in) , not including the height of the carrier or the mating connectors |
Analog Input Modules
Analog input modules receive signals from current and voltage input devices . Modules require a carrier
base (IC200CHSxxx) .
