Product Details:
Payment & Shipping Terms:
|
| Brand: | GE | Model: | IC200ALG328 |
|---|---|---|---|
| Origin: | USA | Packing: | Carton |
| Type: | Industrial Servo Motor | Lead Time: | 5-8 Work Days |
| Highlight: | ewing machine servo motor,electric servo motor |
||
GE VersaMax Micro Analog Expansion Unit PLC IC200ALG328
Display:
Analog Output Modules:
Analog output modules provide voltage or current signals to analog output devices . Modules require a
carrier base (IC200CHSxxx) .
| IC200ALG325 | IC200ALG326 | IC200ALG327 | IC200ALG328 | IC200ALG331 | |
| Product Name | VersaMax Analog Output Module, 13 Bit ±10 VDC or 0 to 10 VDC Voltage, 8 Channel |
VersaMax Analog Output Module, 13 Bit Current, 8 Channel |
VersaMax Analog Output Module, 13 Bit ±10 VDC or 0 to 10 VDC Voltage, 12 Channel |
VersaMax Analog Output Module, 13 Bit, 0 - 20 mA, 4-20 mA Current, 12 Channel |
VersaMax Analog Output Module, 14 Bit Voltage/ Current 1500 VAC Isolation, 4 Channel |
| Lifecycle Status | Active | Active | Active | Active | Active |
| Output Range | ±10 VDC or 0 to 10 VDC | 4 to 20 mA (default) 0 to 20 mA (configured with jumper) |
±10 VDC or 0 to 10 VDC | 4 to 20 mA (default) 0 to 20 mA (configured with jumper) |
±10 VDC, 4-20 mA |
| Number of Channels | 8 | 8 | 12 | 12 single ended, one group | 4 |
| External Power Supply | Range: 18-30 VDC including ripple; Current consumption: 102 mA maximum |
Range: 18-30 VDC including ripple; 2A inrush maximum, 100 mA maximum (no load), 185 mA maximum (all 8 outputs at full scale) |
Range: 18-30 VDC including ripple; Current consumption: 112 mA maximum |
Range: 18-30 VDC including ripple; Current consumption: 2A inrush maximum 100 mA maximum (no load) 270 mA maximum (all 12 outputs at full scale) |
Range: 19 .5-30 VDC including ripple; Current consumption: 100 mA maximum plus load currents |
| Resolution | 1 .25 mV = 4 counts | 4-20 mA: 5 counts = 2 .5 uA (~12 .7 bits) 0-20 mA: 4 counts = 2 .5 uA (13 bits) |
1 .25 mV = 4 counts | 4-20 mA: 5 counts = 2 .5 uA (~12 .7 bits) 0-20 mA: 4 counts = 2 .5 uA (13 bits) |
Current mode: 381 nA nominal Voltage mode: 381 µV nominal |
| Update Rate | 15 .0 ms maximum | 15 .0 ms maximum | 10 .0 ms maximum | 15 ms maximum | 7 ms maximum |
| Accuracy at 25¢XC | ±0 .3% typical of full scale, ±0 .5% maximum of full scale |
±0 .3% of full scale (typical), ±0 .5% of full scale (max .) ±1% of full scale (max .) |
±0 .3% typical of full scale, ±0 .5% maximum of full scale |
+/- 0 .3% of full scale (typical), +/- 0 .5% of full scale (max .) +/-1% of full scale (max .) |
±0 .1% maximum of full scale |
| 5V Backplane Current Consumption (mA) |
50 maximum | 50 maximum | 50 maximum | 50 maximum | 10 maximum |
| 3 .3V Backplane Current Consumption (mA) |
N/A | N/A | N/A | N/A | 115 maximum |
| LED Indicators | FLD PWR LED indicates field power is present . OK LED indicates backplane power is present |
FLD PWR LED indicates field power is present . OK LED indicates backplane power is present . |
FLD PWR LED indicates field power is present . OK LED indicates backplane power is present . |
FLD PWR LED indicates field power is present . OK LED indicates backplane power is present . |
FLD PWR LED indicates the presence of both logic power and user power . OK LED indicates module status |
| Dimensions (W x H x D) | 110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in), not including the height of the carrier or the mating connectors |
110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in), not including the height of the carrier or the mating connectors |
110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in), not including the height of the carrier or the mating connectors |
110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in), not including the height of the carrier or the mating connectors |
110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in), not including the height of the carrier or the mating connectors |
Warranty:
All items new and original , 15 months warranty .
Any inquiries will be replied within 1 hour ,before we send out the goods,
we check them more than three times.
Payment ways:
We accept TT Bank transfer , West Union ,Paypal etc.
Leadtime Our Advantage:
1-3 work days delievery time after confirmed Payment
