• MSMD022P1V Panasonic Industrial Servo Motor 2KHz,0.2KW,200V 106V 2.5A 0.2KW
  • MSMD022P1V Panasonic Industrial Servo Motor 2KHz,0.2KW,200V 106V 2.5A 0.2KW
MSMD022P1V Panasonic Industrial Servo Motor 2KHz,0.2KW,200V 106V 2.5A 0.2KW

MSMD022P1V Panasonic Industrial Servo Motor 2KHz,0.2KW,200V 106V 2.5A 0.2KW

Product Details:

Place of Origin: Japan
Brand Name: Panasonic
Certification: CE
Model Number: MSMD022P1V

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Contact
Packaging Details: NEW AND ORIGINAL
Delivery Time: 3-5DAYS
Payment Terms: T/T, Western Unionm,PAYPAL
Supply Ability: 1000
Get Best Price Contact Now

Detail Information
Brand: Panasonic Model Number: MSMD022P1V
Country Of Origin: Japan Type: Industrial Servo Drives
RATED REV: 3000RPM RATED Freq: 2KHZ
RATED Output: 0.2KW Input: 106V 2.5A
Highlight:

ewing machine servo motor

,

electric servo motor

Product Description

Panasonic Industrial Servo Motor 2KHz,0.2KW,200V MSMD022P1V





MSMD022P1V Description​​

The Panasonic MSMD022P1V is a high-performance, single-split ceiling concealed duct type air conditioner designed for commercial and residential applications. This unit is part of Panasonic's premium lineup, engineered to provide powerful, quiet, and efficient cooling and heating while remaining completely hidden from view within the ceiling space. It is an ideal solution for maintaining consistent and comfortable temperatures in spaces like offices, conference rooms, luxury apartments, and retail stores, where aesthetics and quiet operation are paramount.

​​MSMD022P1V Features​​

  • •
    ​​High Energy Efficiency:​​ Features an inverter compressor that automatically adjusts its power to maintain the desired temperature, significantly reducing energy consumption compared to non-inverter models.
  • •
    ​​Powerful & Rapid Cooling/Heating:​​ Delivers strong cooling and heating capacity, quickly bringing the room to the desired comfort level.
  • •
    ​​Whisper-Quiet Operation:​​ Engineered for minimal noise, ensuring a peaceful environment. The sound pressure level can be as low as 32 dB(A) in low-speed operation.
  • •
    ​​Wide Operating Range:​​ Capable of stable operation in a broad range of outdoor temperatures, providing reliable cooling even in extremely hot conditions.
  • •
    ​​R32 Refrigerant:​​ Utilizes R32 refrigerant, which has a lower Global Warming Potential (GWP) than traditional R410A, making it a more environmentally responsible choice.
  • •
    ​​Flexible Installation:​​ The ducted design allows for flexible installation with custom air ducts and vents to distribute air evenly throughout the space.
  • •
    ​​Advanced Air Purification:​​ Equipped with a high-density filter and optional additional filters (like PM2.5 filters) to effectively remove dust, allergens, and other airborne particles, ensuring healthier indoor air quality.
  • •
    ​​Auto-Restart Function:​​ In the event of a power outage, the unit automatically resumes operation with the previous settings once power is restored.

​​MSMD022P1V Material & Usage​​

  • •
    ​​Materials:​​ The indoor unit features a durable, corrosion-resistant galvanized steel casing. The fan motor and heat exchanger are built with high-quality components for long-term reliability. The air vents are typically made of high-impact ABS plastic.
  • •
    ​​Primary Usage:​​ This ducted mini-split system is specifically designed for installation in the concealed space above a false ceiling. It is connected to ductwork that distributes conditioned air through diffusers grilles installed in the ceiling. It is best suited for:
    • •
      Commercial offices and meeting rooms
    • •
      High-end residential living areas and bedrooms
    • •
      Hotels and restaurants
    • •
      Retail shops and boutiques
    • •
      Any application where a discreet, centralized cooling and heating solution is required.

​MSMD022P1V  ​Important Parameters​​

Parameter
Specification
Notes
​​Model Name​​
MSMD022P1V
Indoor Unit Model
​​Cooling Capacity​​
6.3 kW (22,000 BTU/h)
Rated at specific conditions (e.g., 35°C outdoor)
​​Heating Capacity​​
7.1 kW (24,000 BTU/h)
Rated at specific conditions (e.g., 7°C outdoor)
​​Power Supply (Indoor Unit)​​
220-240 V ~ 50 Hz
Single Phase
​​Rated Cooling Power Input​​
~1.65 kW
Varies with operating conditions (Inverter)
​​Rated Heating Power Input​​
~1.70 kW
Varies with operating conditions (Inverter)
​​Energy Efficiency Rating​​
High (Specific class depends on region, e.g., 5-star in India)
Complies with local standards
​​Refrigerant Type​​
R32
Lower GWP refrigerant
​​Air Flow Volume (Indoor)​​
High / Medium / Low Speeds
Adjustable fan speeds for customized airflow
​​Sound Pressure Level (Indoor)​​
Approx. 32-42 dB(A)
Lower dB at lower fan speeds
​​Net Weight (Indoor Unit)​​
Approximately 25 kg
Weight may vary slightly
​​Connection Pipe Diameter​​
Liquid: 6.35 mm (1/4")
Gas: 12.7 mm (1/2")









Specifications:



Item Specifications
Input power 100 V Main circuit Single phase 100 V ＋10 ％－15 ％　～120 V ＋10 ％－15 ％　50 Hz / 60 Hz
Control circuit Single phase 100 V ＋10 ％－15 ％　～120 V ＋10 ％－15 ％　50 Hz / 60 Hz
200 V Main circuit A-frame to
D-frame		 Single/3-phase 200 V ＋10 ％－15 ％　～240 V ＋10 ％－15 ％　50 Hz / 60 Hz
E-frame,
F-frame		 Single/3-phase 200 V ＋10 ％－15 ％　～240 V ＋10 ％－15 ％　50 Hz / 60 Hz
Control
circuit		 A-frame to
D-frame		 Single phase 200 V ＋10 ％－15 ％　～240 V ＋10 ％－15 ％　50 Hz / 60 Hz
E-frame,
F-frame		 Single phase　200 V ＋10 ％－15 ％　～240 V ＋10 ％－15 ％　50 Hz / 60 Hz
Environment temperature Ambient temperature: 0 ˚C to 55 ˚C (free from freezing)
Storage temperature: –20 ˚C to 65 ˚C
(Max.temperature guarantee: 80 ˚C for 72 hours free from condensation*1)
humidity Both operating and storage : 20 % to 85 %RH (free from condensation*1)
Altitude Lower than 1000 m
Vibration 5.88 m/s2 or less, 10 Hz to 60 Hz
Control method IGBT PWM Sinusoidal wave drive
Encoder feedback 23-bit (8388608 resolution) absolute encoder, 7-wire serial
* When using the product as an incremental system (not using multi-turn data), do not connect a battery for absolute encoder. Instead, set the parameter Pr0.15 to [1] (default).
External scale feedback A/B phase, initialization signal defferential input.
Manufacturers that support serial communication scale:
Fagor Automation S.Coop., Magnescale Co., Ltd., Mitutoyo Corporation Nidec Sankyo Corporation, Renishaw plc
Parallel I/O connector Control signal Input General purpose 10 inputs
The function of general-purpose input is selected by parameters.
Output General purpose 6 outputs
The function of general-purpose output is selected by parameters.
Analog signal Input 3 inputs (16-bit A/D : 1 input, 12-bit A/D : 2 inputs)
Output 2 outputs (Analog monitor: 2 output)
Pulse signal Input 2 inputs (Photo-coupler input, Line receiver input)
Both open collector and line driver interface can be connected.
High speed line driver interface can be connected.
Output 4 outputs ( Line driver: 3 output, open collector: 1 output)
Line driver output for encoder pulses (A/B/Z signal) or external feedback pulses (EXA/EXB/EXZ signal) open collector output also available for Z or EXZ signal.
Communication
function		 USB USB interface to connect to computers for parameter setting or status monitoring.
RS232 1:1 communication
RS485 1: n communication (max 31)
Safety function A dedicated connector is provided for Functional Safety.
Front panel (1) 5 keys
(2) LED (6-digit)
Regeneration A-frame, B,-frame: no built-in regenerative resistor (external resistor only)
C-frame to F-frame: Built-in regenerative resistor (external resistor is also enabled.)
Dynamic brake A-frame to F-frame: Built-in
Control mode Switching among the following 7 mode is enabled,
(1) Position control
(2) Speed control
(3) Toque control
(4) Position/Speed control
(5) Position/Torque control
(6) Speed/Torque control
(7) Full-closed control







Item

Specifications

Control input

(1) servo-ON input
(2) Alarm clear input
(3) Gain switch input
(4) Positive direction drive inhibit input
(5) Negative direction drive inhibit input
(6) Forced alarm input
(7) Inertia ratio switch input

Control output

(1) Servo-alarm output
(2) Servo-ready output
(3) External brake off output
(4) At-speed output
(5) Torque in-limit output
(6) Zero speed detection output
(7) Warning output
(8) Alarm clear attribute output
(9) Servo on status output

Position control

Control input

(1) Deviation counter clear input
(2) Command pulse inhibit input
(3) Command division/multiplication switch input
(4) Anti-vibration switch input
(5) Torque limit switch input
(6) Control mode switch input

Control output

(1) In-position output
(2) Position command ON/OFF output

Pulse
input

Max. command pulse frequency

500 kpps (Optocoupler interface), 8 Mpps (When using line receiver input multiplied by 4)

Input pulse signal format

Differential input. Selectable by parameter.
([1]Positive/Negative pulse [2]A/B quadrature [3]Pulse/Direction)

Electronic gear
(Division/Multiplication of
command pulse)

Applicable scaling ratio: 1/1000 times to 8000 times
Any value of 1 - 2 30 can be set for both numerator (which corresponds to encoder resolution) and denominator (which corresponds to command pulse resolution per motor revolution), but the combination has to be within the range shown above.

Smoothing filter

Primary delay filter or FIR type filter is adaptable to the command input

Analog
input

Torque limit command input

Individual torque limit for both positive and negative direction is enabled.

Torque feed forward input

Analog voltage can be used as torque feed forward input.

Two-degree-of-freedom control

Available

Anti-vibration control

Available

Load variation suppression function

Available

Speed control

Control input

(1) Internal command velocity selection input
(2) Speed zero clamp input
(3) Velocity command sign input
(4) Control mode switch input

Control output

(1) Speed coincidence output
(2) Velocity command ON/OFF output

Analog
input

Velocity command input

Velocity command input with analog voltage is possible. Scale setting and command polarity vary depending on parameters. (6 V/Rated rotational speed: Default)

Torque limit command input

Individual torque limit for both positive and negative direction is enabled.

Torque feed forward input

Analog voltage can be used as torque feed forward input.

Internal velocity command

Switching the internal 8 speed is enabled by command input.

Soft-start/down function

Individual setup of acceleration and deceleration is enabled, with 0 s to 10 s/ 1000 r/min. Sigmoid acceleration/deceleration is also enabled.

Speed zero clamp

Internal velocity command can be clamped to 0 with speed zero clamp input.

Two-degree-of-freedom control

Available

Torque control

Control input

Speed zero clamp input, torque command sign input, control mode switch input.

Control output

(1) Speed coincidence output
(2) Speed in-limit output

Analog
input

Torque command input

Torque command input with analog voltage is possible. Scale setting and command polarity vary depending on parameters. (3 V/rated torque Default)

Speed limit function

Speed limit value with parameter is enabled.

Full-closed control

Control input

(1) Deviation counter clear input
(2) Command pulse inhibit input
(3) Command division/multiplication switch input
(4) Anti-vibration switch input
(5) Torque limit switch input

Control output

(1) In-position output
(2) Position command ON/OFF output

Pulse
input

Max. command pulse frequency

500 kpps (Optocoupler interface), 8 Mpps (When using line receiver input multiplied by 4)

Input pulse signal format

Differential input. Selectable by parameter.
([1]Positive/Negative pulse [2]A/B quadrature [3]Pulse/Direction)

Electronic gear
(Division/Multiplication of
command pulse)

Applicable scaling ratio: 1/1000 times to 8000 times
Any value of 1 - 2 30 can be set for both numerator (which corresponds to encoder resolution) and denominator (which corresponds to command pulse resolution per motor revolution), but the combination has to be within the range shown above.

Smoothing filter

Primary delay filter or FIR type filter is adaptable to the command input

Analog
input

Torque limit command input

Individual torque limit for both positive and negative direction is enabled.

Torque feed forward input

Analog voltage can be used as torque feed forward input.

Setting range of external scale
division/multiplication

1/40 times to 1280 times
Although ratio of the encoder pulse (numerator) and external scale pulse (denominator) can be arbitrarily set in the range of 1 to 2 23 for the numerator and in the range of 1 to 2 23 for the denominator, this product should be used within the aforementioned range.

Two-degree-of-freedom control

Available

Anti-vibration control

Available

Common

Auto tuning

The load inertia is identified in real time by the driving state of the motor operating according to the command given by the controlling device and set up support software “PANATERM”. The gain is set automatically in accordance with the rigidity setting.

Division of encoder feedback pulse

Set up of any value is enabled (encoder pulses count is the max.).

Protective function

Hard error

Over-voltage, under-voltage, over-speed, over-load, over-heat, over-current and
encoder error etc.

Soft error

Excess position deviation, command pulse division error, EEPROM error etc.

Alarm data trace back

Tracing back of alarm data is available
