HG-SN302BJ-S100 2000 R/Min 3.0 KW Mitsubishi Industrial Servo Motor 208-230 / 240 V

Industrial HG-SN302BJ-S100 2000 r/min 3.0 kW Mitsubishi Servo Motor

HG-SN302BJ-S100 Description​​

​​HG-SN302BJ-S100 Features​​

1. 1.
   ​​Medium Inertia Design:​​ The rotor is designed with medium inertia, making it less sensitive to load variations. This ensures superior stability and smooth operation, especially in applications with fluctuating loads or high load-to-motor inertia ratios.
2. 2.
   ​​High Torque Output:​​ Delivers high torque across a wide speed range, from low speeds for heavy-load startup to high speeds for rapid traversal. The rated torque of 14.3 N·m provides substantial driving force.
3. 3.
   ​​High Resolution Encoder:​​ Features a high-resolution 17-bit incremental encoder (131,072 pulses/revolution) for extremely precise position control, minimal speed ripple, and ultra-smooth rotation at very low speeds.
4. 4.
   ​​Electromagnetic Brake:​​ Includes a fail-safe electromagnetic brake that engages when power is cut off, preventing the motor shaft from moving. This is essential for safety in vertical axes and for holding loads in place during power loss.
5. 5.
   ​​IP67 Protection Rating:​​ Offers a high degree of protection against dust and liquids, allowing it to perform reliably in harsh environments where it may be exposed to cutting fluid, oil, or water spray.
6. 6.
   ​​Wide Operating Speed Range:​​ Capable of operating from very low speeds up to a maximum of 2500 rpm, providing flexibility for a variety of speed-control applications.

​​HG-SN302BJ-S100 Material & Applications​​

• •
  ​​Material:​​ The motor housing is constructed from high-quality aluminum alloy for effective heat dissipation. The shaft is made of hardened steel, and the seals are oil-resistant rubber to maintain the IP67 rating. The rotor uses electromagnetic steel and high-energy permanent magnets.
• •
  ​​Primary Applications:​​
  • •
    ​​Large Rotary Index Tables:​​ Precise angular positioning of heavy workpieces.
  • •
    ​​Winding/Unwinding Machines:​​ Providing constant tension control for cables, wires, and sheets.
  • •
    ​​Material Handling:​​ Driving conveyor belts, lifters, and automated transfer systems with heavy loads.
  • •
    ​​Industrial Machinery:​​ Feed axes in large machine tools, injection molding machines, and pressing machines.
