Product Details:
Payment & Shipping Terms:
|
| Brand: | Schneider | Model: | 140CPU67060 |
|---|---|---|---|
| Palce Of Origin: | FR | Series: | Quantum CPUs |
| Marking: | CE | Checks: | Process Control |
| Clock Frequency: | 166 MHz | Weight: | 2bl |
| High Light: | Modicon Quantum PLC CPU Module,M80486 Processor PLC CPU Module,140CPU67060 Quantum CPU Module |
||
Modicon Quantum PLC / CPU 140CPU67060 Single Slot 80486 Processor With Mathematical
| Manufacturer: | Modicon Quantum |
| Series: | Quantum CPUs |
| Weight: | 2 lb |
| Product or component: | Unity processor |
| Clock frequency: | 266 MHz |
| Number of slots: | 10 |
| 16 | |
| 2 | |
| 4 | |
| 6 | |
| Number of racks: | 2 - local rack(s) |
| Number of distributed I/O station: | 63 station(s) - 1 rack(s) - 3 distributed network(s) |
| Number of remote I/O station: | 31 - 2 remote rack(s) |
| Discrete I/O number: | 8000 inputs, 8000 outputs - distributed - per network |
| 31744 inputs, 31744 outputs - remote | |
| Unlimited (26 slots max) - local | |
| Analogue I/O number: | Unlimited (26 slots max) - local |
| 500 inputs, 500 outputs - distributed - per network | |
| 1984 inputs,1984 outputs - remote | |
| Application specific I/O: | Accurate time stamping |
| Counter | |
| High-speed interrupt inputs | |
| Serial link | |
| Number of optional modules: | 6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max) |
| Maximum number of connections: | Unlimited (AS-Interface) - local |
| 6 (Profibus DP) - local | |
| 6 (Modbus Plus) - local | |
| 6 (Ethernet TCP/IP) - local | |
| 4 (AS-Interface) - remote | |
| 2 (AS-Interface) - distributed | |
| 1 (USB) | |
| 1 (Modbus) - RS232/485 Modbus/ASCII | |
| Integrated connection type: | 1 Ethernet TCP/IP |
| 1 Modbus | |
| 1 Modbus Plus | |
| 1 USB | |
| Checks: | Process control |
| Memory description: | Expandable 8 MB - file storage with PCMCIA card |
| Expandable 7168 kB - program with PCMCIA card | |
| Internal RAM 768 kB | |
| Switch function: | Key switch memory port on/off |
| Application structure: | 4 auxiliary tasks |
| 32 timer interrupt tasks | |
| 128 interrupt tasks | |
| 128 I/O interrupt tasks | |
| 1 periodic fast task | |
| 1 cyclic/periodic master task | |
| Execution time per instruction: | 0.48...0.56 µs floating points |
| 0.0525...0.075 µs Boolean | |
| 0.045...0.06 µs on word | |
| 0.045...0.06 µs on fixed-point arithmetic | |
| Execution time for 1 K instruction: | 9.91 65 % Boolean and 35 % numerical |
| 10.28 100 % Boolean | |
| System overhead: | 1 ms - master task |
| 0.2 ms - fast task | |
| Bus current requirement: | 2160 mA |
| Local signalling: | 1 LED red for Ethernet collision |
| 1 LED green for Ethernet activity (COM) | |
| Electrical connection: | 1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus |
| network | |
| 1 connector, connector type: RJ45 for connecting Modbus bus | |
| 1 connector, connector type: RJ45 for connecting Ethernet network | |
| 1 connector, connector type: MT-RJ (fiber optic) for interconnecting primary and | |
| secondary PLCs (hot standby architecture |
TSX-PSY followed by 161, 260, 361, 550 or 552, followed by 0 or 1, may be followed by M.
TSX-REY2002500, TSX-REY2002500F, TSX-REY200K5, TSX-RKA02
TSX-RKY followed by 4, 6, 8 or 12, may be followed by E or X.
TSX-SCP1012, TSX-SCP1014, TSX-SCP1112, TSX-SCP1114, TSX-SUP1011, TSX-SUP1021, TSX-SUP1051, TSX-SUP1101, TSX-SUPA02, TSX-SUPA03, TSX-TLYEX, TSXWMY100, UNY-XCA-USB33, YCP-MFPP128
TSX57 Series programmable controllers Model(s) BATM01, BATM02, BATM03, BATM101, NTP100, TSX DMY28FK, TSX DMY28RFK, TSX-CRJDB25, TSX-CRJMD25, TSX-CUSB232, TSX-CUSB485, TSX-ESY007, TSX-ETG1000, TSX-ETG1010, TSX-ETG3000, TSX-ETG3010, TSX-ETG3021, TSX-ETG3022, TSX-ETG3030, TSX-FPP10, TSX-FPP20, TSX-FPP200, TSX-SCY11601, TSX-SCY21601, TSXETY4103, TSXTVSY100, TSXUSBFIP
XPSMF60 Series afe analog output cards Model(s) XPSMFAO801
XPSMF60 Series CPU modules Model(s) XPSMFCPU22
XPSMF60 Series digital (24) input units Model(s) XPSMFDI2401
XPSMF60 Series digital (32) input units Model(s) XPSMFDI3201
XPSMF60 Series housing with bus (6 E/A places) Model(s) XPSMFGEH01
XPSMF60 Series power supplies Model(s) XPSMFPS01
XPSMF60 Series relay output units Model(s) XPSMFDO801
XPSMF60 Series safe analog input cards Model(s) XPSMFAI801
XPSMF60 Series safe counter modules Model(s) XPSMFCIO2401
XPSMF60 Series safe digital I/O modules Model(s) XPSMFDIO241601
Investigated to UL 61010-1 and UL 61010-2-201
Accessory Open type Box Unit Model(s) HMIG5U2
Accessory Open type memories, cables, terminal blocks, covers, bundles, "Modicon M340 and M580, Accessories (memories, cables, terminal blocks, covers, bundles, ?)" Model(s) ABE7, followed by CPA, followed by 2 or 3 digit number
