SGM-08A3TE11 High Torque Industrial Servo Motor Yaskawa 750W 2.39 N.M 3000RPM

Name: SGM-08A3TE11 High Torque Industrial Servo Motor Yaskawa 750W 2.39 N.M 3000RPM
Brand: Shenzhen Wisdomlong Technology CO.,LTD
SKU: SGM-08A3TE11
Price: 10000.00 USD
Availability: InStock

Product Details:

Place of Origin:	Japan
Brand Name:	Yaskawa
Certification:	CE
Model Number:	SGM-08A3TE11

Detail Information

Place of Origin:

Japan

Brand Name:

Yaskawa

Certification:

Model Number:

SGM-08A3TE11

Brand:

Yaskawa

Model Number:

SGM-08A3TE11

Country Of Origin:

Japan

Type:

Servo Motor

Power - Rated:

850w

Voltage - Rated:

100, 200VAC

RPM:

3000 RPM

Weight:

0.705 Lb (319.78g)

Highlight:

High Light

Highlight:

SGM-08A3TE11 High Torque Industrial Servo Motor

750W High Torque Industrial Servo Motor

SGM-08A3TE11 Servo Motor In Industry

Trading Information

Minimum Order Quantity:

Price:

Contact

Packaging Details:

NEW AND ORIGINAL

Delivery Time:

3-5DAYS

Payment Terms:

T/T, Western Unionm,PAYPAL

Supply Ability:

1000

Product Description

SGM-08A3TE11 Yaskawa Industrial Servo Motor 750W 2.39 N.m 3000RPM

SGM-08A3TE11 Description

The SGM-08A3TE11 is a compact, high-performance AC servo motor from Yaskawa Electric's Sigma-5 series. Designed for precise motion control in space-constrained automation equipment, it offers excellent torque characteristics, fast response, and smooth operation. This motor is ideal for applications requiring high accuracy and reliability, such as small-scale robotics, semiconductor handling, medical devices, and precision assembly systems. It is engineered to pair seamlessly with Yaskawa's Sigma-5 servo amplifiers for optimized system performance.

SGM-08A3TE11 Features

Compact and Lightweight: Small frame size and low weight enable easy integration into compact machinery and moving parts.
High Torque Density: Delivers high torque relative to its size, providing strong acceleration and dynamic performance.
Low Cogging and Smooth Rotation: Advanced magnetic circuit design minimizes torque ripple, ensuring stable operation even at very low speeds.
High-Resolution Encoder: Features a 20-bit single-turn absolute encoder for precise positioning and stable speed control.
High Response Bandwidth: Excellent frequency response allows rapid settling and tracking, improving cycle times.
IP65 Protection Rating: Offers dust-tight and water-jet resistant protection, suitable for environments with dust or light moisture.
Oil-Resistant Design: Selected models (often indicated by suffix) include oil-resistant seals for environments exposed to oil mist or splash.

SGM-08A3TE11 Material & Applications

Materials: Housing is aluminum alloy for lightweight strength. Internal components include high-grade electromagnetic steel laminations, copper windings with Class F insulation, and rare-earth permanent magnets. The shaft is hardened steel.
Primary Applications:
- Small industrial robots (SCARA, Cartesian, delta robots)
- Semiconductor wafer handling and inspection equipment
- Precision medical and laboratory automation
- Compact machine tools and PCB drilling/routing machines
- Packaging machines for small products
- Automated optical inspection systems

SGM-08A3TE11 Key Parameters

Parameter	Specification
Motor Series	Yaskawa Sigma-5 Miniature Low-Inertia
Motor Frame Size	80 mm
Rated Output Power	750 W
Rated Torque	2.39 Nm
Maximum Torque	7.16 Nm
Rated Speed	3000 rpm
Maximum Speed	6000 rpm
Rotor Moment of Inertia	1.53 × 10⁻⁴ kg·m²
Voltage Rating	200 VAC (Three-phase)
Encoder Type	20-bit Absolute Encoder (Single-turn)
Protection Rating	IP65 (Oil-proof specification may vary; suffix indicates specifics)
Insulation Class	Class F (155°C)
Ambient Temperature	0°C to 40°C (Operation), -20°C to 80°C (Storage)
Vibration Level	Under 2.5 mm/s (Per ISO standards)
Shaft Configuration	Straight shaft with keyway
Weight	Approximately 3.5 kg
Brake Option	Typically available as an option (model suffix indicates brake type)
Connector Type	Waterproof connector (specific type per model)
