ACS355-03E-02A4-4 ABB Variable Frequency Inverter 3AC 400V 18A 0-500HZ

Name: ACS355-03E-02A4-4 ABB Variable Frequency Inverter 3AC 400V 18A 0-500HZ
Brand: Shenzhen Wisdomlong Technology CO.,LTD
SKU: ACS355-03E-02A4-4
Price: 10000.00 USD
Availability: InStock

Product Details:

Place of Origin:	Switzerland
Brand Name:	ABB
Certification:	CE
Model Number:	ACS355-03E-02A4-4

Detail Information

Place of Origin:

Switzerland

Brand Name:

ABB

Certification:

Model Number:

ACS355-03E-02A4-4

Rating Power:

55KW

Output Current:

2.4A

Size:

970*370*560 Mm

Power Phase:

3-phase

Output:

3AC 400V 18A

Device Short Name:

TV630

Output Frequency:

0-500HZ

Accelerationtime:

0.1-6000 Seconds

Trading Information

Minimum Order Quantity:

Price:

negotiation

Packaging Details:

New and Original

Delivery Time:

5-7 days

Payment Terms:

T/T, L/C

Supply Ability:

100

Product Description

ACS355-03E-02A4-4 ABB Variable Frequency Inverter 3AC 400V 18A 0-500HZ

ACS355-03E-02A4-4 Overview

The ABB ACS355-03E-02A4-4 is a compact AC frequency inverter from ABB's ACS355 series, designed for general-purpose motor control applications. This versatile drive offers sensorless vector control technology for precise speed and torque regulation of three-phase AC motors. With its 0.75kW rated output power and 380-480V input voltage range, it provides reliable performance for various industrial automation systems.

ACS355-03E-02A4-4 Key Features

Advanced Control Technology

Sensorless vector control for precise motor speed and torque regulation
Supports both asynchronous motors and permanent magnet synchronous motors
Speed control range of 0-500Hz (extendable to 600Hz)
Real-time monitoring and diagnostics capabilities
Built-in PID controller for pump and fan applications

Robust Communication Interface

Supports multiple industrial protocols including Modbus, CANopen, and Profibus
Easy integration with PLCs, HMIs, and upper-computer systems
Remote monitoring and control capabilities
Programmable via DriveWindow software or ABB FlashDrop tool

Enhanced Safety and Protection

Safe Torque Off (STO) function to SIL 3 safety level
Built-in EMC filter for electromagnetic compatibility
Comprehensive protection functions including overcurrent, overvoltage, and overtemperature
Sequence programming and real-time clock functions

Easy Installation and Operation

Compact wall-mount design (169mm×70mm×161mm)
DIN rail mounting capability
2 analog inputs, 5 digital inputs, 1 analog output, 1 digital output, and 1 relay output
Real-time automatic tuning for easy setup
Pre-programmed application macros

ACS355-03E-02A4-4 Materials and Applications

Construction Materials

The ACS355-03E-02A4-4 is constructed with high-quality electronic components and industrial-grade materials. The unit features durable connectors, robust housing with IP20 protection, and reliable cooling systems designed for industrial environments. The internal components include advanced power electronics and digital signal processors for precise control.

Primary Applications

Pump and fan control systems
Conveyor systems and material handling equipment
Food and beverage processing machinery
Textile machinery and automation systems
Packaging equipment and printing presses
HVAC systems and building automation
General industrial machinery requiring variable speed control

ACS355-03E-02A4-4 Technical Specifications

Parameter	Specification
Model Number	ACS355-03E-02A4-4
Series	ACS355 Series
Rated Output Power	0.75 kW
Rated Output Current	2.4 A
Input Voltage	3-phase AC 380-480V, 50/60Hz
Output Frequency Range	0-500 Hz (extendable to 600Hz)
Control Mode	Sensorless Vector Control
Overload Capacity	150% for 60 seconds every 10 minutes, 175% for 2 seconds at start
Protection Class	IP20
Dimensions	169mm × 70mm × 161mm
Weight	1.2 kg
Mounting Type	Wall mount or DIN rail
Cooling Method	Natural convection
Input Interfaces	2 analog inputs, 5 digital inputs
Output Interfaces	1 analog output, 1 digital output, 1 relay output
Communication Protocols	Modbus, CANopen, Profibus
Braking Capability	15 seconds every 120 seconds (with external resistor)
Operating Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Relative Humidity	90% RH or less (non-condensing)
Certification	CE compliant
Heat Loss	161.2W at maximum output
