FX1N-24MR-ES/UL| Mitsubishi Electric | Fx1n Series Programmable Controllers

Description of  FX1N-24MR-ES/UL

The Mitsubishi FX1N-24MR-ES/UL is a programmable logic controller (PLC) with 24 input/output points and relay outputs. This model is suitable for small to medium-sized automation projects and operates on a 100-240V AC power supply. It offers durability and flexibility, making it a reliable solution for industrial applications.

The Mitsubishi FX1N-24MR-ES-UL (FX1N24MRESUL) is an input/output control module from the FX series. Like other constituent modules of the FX1N series, this module is very compatible with modules of other PLCs from the FX group; it is amiable to FX2N module due to sharing many of the FX2NS I/O and special function blocks. The programming structure of the FX1N-24MR-ES-UL is identical to that of the FX1S, while also sharing the same expansion board.

The FX1N-24MR-ES-UL has a total of 24 points: 14 DC input points and 10 relay output points. The input voltage and frequency of this control module is 100-240VAC and 50/60Hz, and the power consumption wattage is 30W. The FX1N-24MR-ES-UL’s DC/AC voltage is 30VDC/240VAC and its output current is 2A.The dimensions of this module, in width times height times depth, is 90mm by 90mm by 75mm (3.54in by 3.54in by 2.95in) The FX1N-24MR-ES-UL control module itself weighs 0.99lb (0.45kg).

Some features of the FX1N-24MR-ES-UL are as what follows. The control module has a maintenance free, incorporated EEPROM user memory. The EEPROM user memory permits up to 8,000 PLC program steps. Extrinsic EEPROM memory cassettes can be utilized for PLC program storage. It also has an amalgamated serial interface that can allow for communication between an HMI and a personal computer.

Lastly, the FX1N-24MR-ES-UL should be in a room whose temperatures are between 32 and 131oF (0 to 50oC) or while in storage, the temperatures should be between -4 to 158 degrees Fahrenheit (-20 to 70 degrees Celsius) to keep the standard operations functioning properly.

Technical Analysis of  FX1N-24MR-ES/UL:

    Input/Output Configuration: The FX1N-24MR-ES/UL features 14 digital inputs and 10 relay outputs. The inputs operate at 24V DC and support both sink and source connections. The relay outputs are suitable for controlling industrial devices such as motors and lights, with each output capable of handling up to 2A of current.

    Power Supply and Dimensions: This PLC operates on a 100-240V AC power supply, consuming approximately 30W. Its compact design makes it ideal for installation in confined spaces, and it can be mounted on a DIN rail or directly onto a panel.

    Output Protection: The relay outputs do not have built-in protection, so it is recommended to use external devices like fuses or diodes to guard against overloads and voltage surges. This ensures reliable operation and extends the device's lifespan.

    Programming: The FX1N-24MR-ES/UL can be programmed using GX Developer and GX Works2 software. These platforms provide user-friendly interfaces for configuring input/output settings and managing automation processes.

Recommendations and Tips of  FX1N-24MR-ES/UL:

The FX1N-24MR-ES/UL is a powerful and reliable solution for industrial automation projects. It is essential to use external protective devices to safeguard the relay outputs from overloads. Additionally, GX Developer and GX Works2 make programming easy, speeding up the setup process. To ensure optimal performance, regularly check Mitsubishi’s official resources for software updates.
