IC200ALG630-CB GE FANUC Redundant Power Supply Module -40 °C To +70 °C

IC200ALG630-CB  Description

IC200ALG630-CB Features

• High-Density, Multi-Channel Design:​ Provides six fully isolated analog input channels in a single module, optimizing rack space and reducing system cost per point compared to lower-density alternatives.
• Flexible Input Ranges:​ Each channel is independently configurable via software (using Proficy Machine Edition or similar) to accept a variety of standard analog signals, including 0-5V, 0-10V, ±5V, ±10V voltage inputs, and 0-20mA or 4-20mA current inputs, offering exceptional versatility for connecting diverse sensors.
• High Resolution and Accuracy:​ Features 16-bit analog-to-digital conversion, providing fine resolution for precise measurement. High channel-to-channel and channel-to-bus isolation minimizes noise and ground loop interference, ensuring accurate and stable readings in electrically noisy industrial environments.
• Integrated Diagnostics:​ The module includes comprehensive diagnostic capabilities such as open wire detection for 4-20mA loops, over-range and under-range alarms, and module health status. These are reported to the CPU, enabling proactive maintenance and rapid troubleshooting.
• Hot Swappable:​ As part of the VersaMax system, the module supports hot swapping (when used with a compatible CPU and power supply), allowing for replacement or addition without powering down the entire control system, maximizing uptime.
• Easy Configuration and Integration:​ Configuration is performed entirely within the PLC programming software, with no physical DIP switches or jumpers to set. It seamlessly integrates into the VersaMax rack and is recognized automatically by the CPU.

IC200ALG630-CB Materials & Application

• Primary Materials:
  • Module Housing:​ High-strength, flame-retardant thermoplastic (e.g., polycarbonate blend) for durability and safety.
  • Internal Circuitry:​ Multi-layer printed circuit board (PCB) with conformal coating for protection against humidity and contaminants. High-grade analog components, isolation barriers (opto-couplers/isolators), and a 16-bit ADC (Analog-to-Digital Converter).
  • Connectors:​ Robust, locking terminal block connector (the "-CB" suffix typically denotes a removable connector type) for secure field wiring.
  • Status Indicators:​ LED indicators (such as PWR, OK, and per-channel status) made with durable LEDs and light pipes.
• Primary Applications:
  • Process Variable Monitoring:​ Reading signals from temperature transmitters (via thermocouples/RTD transmitters), pressure transducers, level sensors, and flow meters.
  • Machine Automation:​ Monitoring analog feedback from position sensors, potentiometers, load cells, and analog tachometers.
  • Environmental Control:​ Integrating with HVAC systems to read humidity, temperature, and pressure sensors in building automation.
  • Batch and Mixing Processes:​ Precisely measuring ingredient volumes, tank levels, and process variables like pH or conductivity.
  • Energy Management:​ Monitoring current and voltage signals for power consumption analysis.

IC200ALG630-CB Key Technical Parameters
