Q06HCPU-A Mitsubishi 30k Steps Universal Model Redundant Power Supply Module

Q06HCPU-A Features

1. Superior Processing Performance:​ Features a powerful multi-core RISC processor enabling ultra-fast basic instruction execution (LD: 34 ns) and large-capacity program memory (60 KB program capacity, 2520 Kbytes for data/device), handling complex control with ease.
2. Large-Scale System Control:​ Supports control of up to 4 base units and a maximum of 4096 I/O points, making it ideal for extensive and distributed automation systems.
3. Advanced Network & Connectivity:​ Equipped with a built-in 10BASE-T/100BASE-TX Ethernet port for high-speed data communication, MES/ERP integration, and remote monitoring. It also seamlessly integrates with MELSECNET/H, CC-Link, and other field networks for comprehensive system configuration.
4. Multi-CPU Configuration:​ Supports the advanced "Multiple CPU System" configuration, allowing up to 4 CPUs (e.g., Process CPU, Motion CPU, PC CPU) to operate in a single base unit. This enables functional specialization, parallel processing, and high-performance, integrated control (logic, motion, computing).
5. Enhanced Data Handling & Reliability:​ Offers extensive file register capacity, SFC (Sequential Function Chart) programming for complex sequences, and robust self-diagnostics. Features a battery-less design for the standard RAM, reducing maintenance, and supports error logging for improved troubleshooting.
6. High-Speed Processing & Interrupts:​ Includes multiple high-speed interrupt inputs and a dedicated multi-point high-speed counter function, ensuring precise and timely response to critical events and high-speed signals.

Q06HCPU-A Material & Primary Applications

• Material/Construction:​ The module is housed in a rugged, industrial-grade plastic casing with a metal mounting bracket. Internal components, including the high-density multi-layer PCB, high-speed processor, and memory chips, are designed and tested to operate reliably in harsh industrial environments with electrical noise, vibration, and wide temperature ranges.
• Primary Applications:
  • Large-scale factory automation (FA) systems
  • Complete production line control and monitoring
  • Building automation and centralized control systems (BMS)
  • Water treatment and environmental control plants
  • High-speed packaging and material handling systems
  • Complex process control in chemical or pharmaceutical industries
  • Systems requiring tight integration of logic, motion, and information processing.

Q06HCPU-A Key Specifications
