Product Details:
Payment & Shipping Terms:
|
| Brand: | GE | Model: | IC200MDL243 |
|---|---|---|---|
| Origin: | USA | Type: | Module |
| Highlight: | ewing machine servo motor,ac servo motor |
||
120 VAC Isolated, 16 points GE IC200MDL243 VersaMax Discrete Input Module
Discrete Input Modules
Discrete input modules receive signals from input devices such as sensors, pushbuttons, and switches
that can have two states: on or off, open or closed . Modules require a carrier base (IC200CHSxxx) .
| IC200MDL243 | IC200MDL244 | IC200MDL631 | |
| Product Name | VersaMax Discrete Input Module, 120 VAC Isolated, 16 points |
VersaMax Discrete Input Module, 240 VAC Isolated, 8 points |
VersaMax Discrete Input Module 125 VDC, Pos/Neg Logic, Isolated, 8 points |
| Lifecycle Status | Active | Active | Active |
| Input Voltage | 0-132 VAC | 0-264 VAC | 0-150 VDC, 125 VDC nominal |
| Number of Points | 16 | 8 | 8 isolated inputs |
| Channel to Channel Isolation | Yes | Yes | Yes |
| Input and Output Response Time- On/Off (ms) |
1 cycle/2 cycles | 1 cycle/2 cycles | 0 .5 maximum |
| Points per Common | 16 groups of 1 | 8 groups of 1 | 8 groups of 1 |
| On State Current | 5 mA minimum | 7 mA minimum | 1 .0 mA minimum |
| Off State Current | 2 .5 mA maximum | 3 mA maximum | 0 to 0 .1 mA maximum |
| Input Impedance | 8 .6 kOhms (reactive) at 60 Hz, typical; 10 .32 kOhms (reactive) at 50 Hz, typical |
38 .5 kOhms (reactive) at 60 Hz, typical; 46 .3 kOhms (reactive) at 50 Hz, typical |
74 K Ohm typical at 125 VDC |
| 5V Backplane Current Consumption (mA) |
100 maximum | 60 maximum | 40 maximum |
| LED Indicators | One LED per point shows individual point ON/OFF status . OK LED indicates backplane power is present |
One LED per point shows individual point ON/OFF status . OK LED indicates backplane power is present |
One LED per point shows individual point ON/OFF status . OK LED indicates backplane power is present |
| Dimensions (W x H x D) | 110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in), not including the height of the carrier or the mating connectors |
110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in), not including the height of the carrier or the mating connectors |
110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in), not including the height of the carrier or the mating connectors |
